Versatile: allows printing on mugs from 11 to 15 oz, tumblers, bottles, and similar items up to 30 oz
Compact and lightweight design: with a fully integrated resistance in the casing
Automatic pressure adjustment: the resistance adapts to the object's diameter with the appropriate pressure without manual adjustment
Programmable temperature and time: easily set from the control panel. Adjust the temperature range between 100 and 200 °C
Automatic opening: when the timer finishes, the press emits an acoustic signal and opens
Repeats established settings: memorises the last parameters and allows their use in the next pressing
Automatic shutdown: after 15 min of inactivity. Before shutting down, it will beep and the lights will flash
Emergency stop function: press any button to interrupt the pressing
CE Certification: ensures this press meets the technical requirements demanded in the European Union
THINGS TO KEEP IN MIND
If the object to be sublimated has a smaller diameter than the press's resistance allows, you can use silicone sheets to increase the diameter. You can find them in Related Products
If you wish to customise the entire surface of the cylindrical object, it is recommended to perform the sublimation in 2 parts. After the first pressing, slightly rotate the item and press again for 30 seconds. This ensures a complete and uniform customisation
This press has a closed casing structure and is not user-serviceable. For this reason, it does not have replacement resistances
WHAT DOES THE LOKLIK AUTOMATIC PRESS INCLUDE?
1
Pair of thermal protective gloves
1
Roll of thermal adhesive tape
1
User manual
1
Warranty card
CONTROL PANEL
Power button: ON/OFF, after turning on, the button will flash with a white light
Temperature button: press to adjust the value. Holding it for 2 seconds switches from ºC to ºF and vice versa
Time button: press to adjust the value
+/- buttons: allows increasing and decreasing temperature and time values. Short press for intervals of 5 and long press for intervals of 10
Start button (LokLik icon): will turn green when the press reaches the set pressing temperature. Pressing it activates the pressing
MANUFACTURER'S RECOMMENDED PARAMETERS
Parameters are for guidance only and are specified in the manual provided with the heat press. We recommend carrying out tests before starting production.
Connect the press to the power supply and turn it on by pressing the ON/OFF button
Set the desired temperature and time settings
When the red light changes to green, insert the object
Once inserted, press the Start button and the press will close automatically
The transfer will be complete when the timer ends and you hear a beep
The press will open automatically once the pressing time is finished
Remove the customised object with the help of gloves and let it cool
PRECAUTIONS
Do not place unsuitable products
The object must be clean, without any liquid, oil, or dust
Use on a stable, flat, and heat-resistant surface
Avoid touching the resistance when it is hot
Turn off the machine when not in use
When there are beeps and E1 or E2 appears on the LED screen, immediately cut the power and restart
TECHNICAL DATA
Type of press
Automatic / Mugs
Model
Auto Tumbler Heat Press HPT01
Voltage (V | HZ)
220 | 50
Power (W)
550
Temperature (ºC | °F)
100-200 | 210-390
Time (s)
1-600
Cable length (m)
1.8
Compatible diameter (cm)
Ø7.5-Ø8.5
Max. compatible length (cm)
24 cm
Press size (cm)
32.8 x 27.8 x 16
Packaging (cm)
39 x 33.5 x 20.5
Net weight (kg)
4.3
Gross weight (kg)
5
RESISTANCE MEASUREMENTS
Measurements with indicative character provided by the manufacturer. It is recommended to conduct tests on the resistance with the product to be customised before starting production.
