Supplied in a box you can reuse to ship the personalised photo panel
Delivered in an A5, A4 or A3 twist wrap mailer. You can reuse it to deliver the sublimated photo panel or buy more in Related Products
THINGS TO KEEP IN MIND
The customisable side has a clear plastic protective film that needs to be removed before sublimating. The film on some photopanels includes an additional layer of paper to further protect the surface. Easily removable
Stands and hooks not included. Find different options in Related Products
The box will be sealed with tape and a label. They can be easily removed without damaging the box, so you can reuse it
DATA SHEET
Reference no
Shape
Dimensions (cm)
Digital format
Weight (g)
051301
Rectangular
9 x 12
3:4
54
051302
Rectangular
10 x 15
3:2
78
035437
Oval
10 x 15
3:2
58
051303
Rectangular
13 x 18
---
118
051304
Rectangular
15 x 15
1:1
112
051307
Rectangular
20 x 30
2:3
308
051308
Rectangular
24 x 32
3:4
396
RECOMMENDED INSTRUCTIONS AND PARAMETERS FOR SUBLIMATION PRINTING
Print the design in mirror image
Preheat the press to 200°C
Use a Nomex felt pad on the lower platen for even heat distribution (Ref. 922929)
Place the photo panel on the Nomex pad with the printed paper on it. Fix it with heat-resistant tape
https://www.brildor.com/en/sublimation-wood-photo-panel-6mm49578Sublimation MDF Photo Panels 6mm<p class="enlace"><a id="know-more"></a> </p>
<h2><strong>More information about the sublimation MDF photo panels 6mm<br></strong></h2>
<p> </p>
<p><strong>INDEX</strong></p>
<p>> <a href="#know-more1">Description</a></p>
<p>> <a href="#know-more2">Things to keep in mind</a></p>
<p>> <a href="#know-more4">Data sheet</a></p>
<p>> <a href="#know-more5">Recommended instructions and parameters for sublimation printing</a></p>
<p> </p>
<p class="enlace"><a id="know-more1"></a> </p>
<p><strong>DESCRIPTION</strong></p>
<ul>
<li>Black edges and dark brown backing</li>
<li>Supplied in a box you can reuse to ship the personalised photo panel</li>
<li>Delivered in an A5, A4 or A3 twist wrap mailer. You can reuse it to deliver the sublimated photo panel or buy more in <strong>Related Products</strong></li>
</ul>
<p class="enlace"><a id="know-more2"></a> </p>
<p><strong>THINGS TO KEEP IN MIND</strong></p>
<ul>
<li>The customisable side has a clear plastic protective film that needs to be removed before sublimating. The film on some photopanels includes an additional layer of paper to further protect the surface. Easily removable</li>
<li>Stands and hooks not included. Find different options in <strong>Related Products</strong></li>
<li>The box will be sealed with tape and a label. They <strong>can be easily removed</strong> without damaging the box, so you can reuse it</li>
</ul>
<p> </p>
<p class="enlace"><a id="know-more4"></a> </p>
<p><strong>DATA SHEET<br></strong></p>
<table>
<tbody>
<tr>
<td style="text-align: center;"><strong>Reference no</strong></td>
<td style="text-align: center;"><strong>Shape<br></strong></td>
<td style="text-align: center;"><strong>Dimensions<br>(cm)<br></strong></td>
<td style="text-align: center;"><strong>Digital<br>format<br></strong></td>
<td style="text-align: center;"><strong>Weight<br>(g)<br></strong></td>
</tr>
<tr>
<td style="text-align: center;"><strong>051301<br></strong></td>
<td style="text-align: center;">Rectangular</td>
<td style="text-align: center;"><span class="azul-negrita">9 x 12</span></td>
<td style="text-align: center;">3:4</td>
<td style="text-align: center;"><span class="azul-negrita">54</span></td>
</tr>
<tr>
<td style="text-align: center;"><strong>051302</strong></td>
<td style="text-align: center;">Rectangular</td>
<td style="text-align: center;"><span class="azul-negrita">10 x 15</span></td>
<td style="text-align: center;">3:2</td>
<td style="text-align: center;"><span class="azul-negrita">78</span></td>
</tr>
<tr>
<td style="text-align: center;"><strong>035437</strong></td>
<td style="text-align: center;">Oval</td>
<td style="text-align: center;"><span class="azul-negrita">10 x 15</span></td>
<td style="text-align: center;">3:2</td>
<td style="text-align: center;"><span class="azul-negrita">58</span></td>
</tr>
<tr>
<td style="text-align: center;"><strong>051303<br></strong></td>
<td style="text-align: center;">Rectangular</td>
<td style="text-align: center;"><span class="azul-negrita">13 x 18</span></td>
<td style="text-align: center;">---</td>
<td style="text-align: center;"><span class="azul-negrita">118</span></td>
</tr>
<tr>
<td style="text-align: center;"><strong>051304</strong></td>
<td style="text-align: center;">Rectangular</td>
<td style="text-align: center;"><span class="azul-negrita">15 x 15</span></td>
<td style="text-align: center;">1:1</td>
<td style="text-align: center;"><span class="azul-negrita">112</span></td>
</tr>
<tr>
<td style="text-align: center;"><strong>051307</strong></td>
<td style="text-align: center;">Rectangular</td>
<td style="text-align: center;"><span class="azul-negrita">20 x 30</span></td>
<td style="text-align: center;">2:3</td>
<td style="text-align: center;"><span class="azul-negrita">308</span></td>
</tr>
<tr>
<td style="text-align: center;"><strong>051308</strong></td>
<td style="text-align: center;">Rectangular</td>
<td style="text-align: center;"><span class="azul-negrita">24 x 32</span></td>
<td style="text-align: center;">3:4</td>
<td style="text-align: center;"><span class="azul-negrita">396</span></td>
</tr>
</tbody>
</table>
<p> </p>
<p><a name="know-more5"></a></p>
<p><strong>RECOMMENDED INSTRUCTIONS AND PARAMETERS FOR SUBLIMATION PRINTING<br></strong></p>
<ul>
<li>Print the design in <strong>mirror image</strong></li>
<li>Preheat the press to <span class="azul-negrita">200°C</span></li>
<li>Use a Nomex felt pad on the lower platen for even heat distribution (<a href="https://www.brildor.com/en/nomex-felt-pad" target="_blank" rel="noopener">Ref. 922929</a>)</li>
<li>Place the photo panel on the Nomex pad with the printed paper on it. Fix it with heat-resistant tape</li>
<li>Press for <span class="azul-negrita">70-80 seconds</span>, <strong>medium pressure</strong></li>
<li>Use a protective glove to remove the photo panel</li>
<li>Carefully peel off the paper</li>
</ul>
<p> </p>https://www.brildor.com/media/catalog/product/f/o/fotopaneles-serie-manisa-d10.jpg1.95instock01.95000https://www.brildor.com/media/catalog/product/f/o/fotopaneles-serie-manisa-d10.jpg42959431744943549531496365030850317/Blanks/Blanks/Only at Brildor/Blanks/Sublimation Photo Panels/Blanks/Sublimation Photo Panels/Wood/Blanks/Picture Frames & Photo Panels2023-02-06T07:38:05+0000
