DESCRIPTION

SUBLI Up Patch is a heat-adhesive sublimable polyester fabric (white) for textile transfer on light and dark fabrics.

• Sublimable on the textured fabric side
• The support or liner is an adhesive polyester film
• Manufactured in Germany by Poli-Tape

THINGS TO KEEP IN MIND

• For small composite designs, it may be convenient to use a carrier to facilitate the application of the vinyl. In such cases, it is recommended to use the Poli-Tack 854 or Poli-Tack 850 carrier, see Related Products
• If using a carrier, note that being polyester, some ink may remain due to resublimation. To avoid this, we recommend a short press (2-3 seconds), remove the carrier from the vinyl, and finish pressing
• After printing the vinyl with sublimation ink, it should be left to dry. It can be transferred to the garment when the ink is dry to the touch
• It should be printed using cut marks to be able to cut it with the plotter
• For very small designs, we recommend using SubliTex

TRANSFER PARAMETERS

• Temperature: 190 ºC
• Pressure: low
• Time: 30 seconds

TRANSFER PARAMETERS FOR HEAT-SENSITIVE FABRICS

• Temperature:
  • 190 ºC (ink activation)

  • 160 ºC (transfer)
• Pressure: 2.5-3.0 bar [medium pressure]
• Time:
  • 30 seconds (ink activation)

  • 15 seconds (transfer)

APPLICATION INSTRUCTIONS

• Print the design directly onto the vinyl in direct mode
• Let the ink dry
• When the ink is dry to the touch, remove the excess vinyl (weeding operation)
• If using a carrier, adhere it to the vinyl with the help of a spatula
• Heat the press to 190 ºC
• Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
• Peel the vinyl from its backing and place it on the garment
• Press with low pressure for 30 seconds

APPLICATION INSTRUCTIONS FOR HEAT-SENSITIVE FABRICS

• Print the design directly onto the vinyl in direct mode
• Remove the excess vinyl (weeding operation)
• If using a carrier, adhere it to the vinyl with the help of a spatula
• Heat the press to 190 ºC
• Place the vinyl on the press and put protective paper on top
• Press with low pressure for 30 seconds
• Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
• Peel the vinyl from its backing and place it on the garment
• Place protective paper
• Press at 160 ºC with medium pressure for 15 seconds

WASH RESISTANCE

• Wash resistance: max. 40ºC
• Wash the garment inside out
• Use only colour detergent

RELATED POSTS

Complete guide on printable textile vinyl

TECHNICAL SHEET

Technical sheet Subli Up Patch (.pdf - 0.04 MB)

SAFETY SHEET

Proper handling of this product will not lead to the formation or release of hazardous components. This product is not classified as dangerous goods under current GefStoffV legislation or under European Union criteria. Therefore, the preparation of a safety sheet is not mandatory in this case. The safety sheet serves only to fulfil the informational requirements under statute (EG) No. 1907/2006 (REACH) and can be sent upon request. This product is neither classified as dangerous goods under transport legislation nor composed of high-risk liquid substances, complying with household health regulations. Waste generated from the application and end-of-life cycle of the product must comply with the legal disposal standards of the respective national authorities.
