Rip Software CADlink Digital Factory v10 DTF Edition

Rip software CADlink Digital Factory V10, specially developed for DTF printing. Full image control to achieve high-quality printing by optimising the printing process.

  • USB dongle licence, compatible with Windows®.
  • Compatible with design software such as Photoshop, Illustrator and CorelDRAW.
  • Suitable for DTF printers.
  • Ability to work with many different formats and substrates.
  • There is also an extension available for this licence that will allow you to: use the software on up to 3 different devices and print up to 43.2 cm wide

More information

Rip Software CADlink Digital Factory v10 DTF Edition Ref: 040631
Rip Software CADlink Digital Factory v10 DTF Edition
€389.00 VAT not included / Each Unit
Availability Immediate: 5 units
License Extension CadLink Digital Factory v10 DTF Ref: 048210
License Extension for Up to 3 Printers for CadLink Digital Factory v10 DTF
€175.00 VAT not included / Each Unit
Availability On request, 10/12 working days after confirmation
View Price
VAT not included
Reward Points
Get free € to redeem on your next order by buying these products. Discover the Brildor Loyalty Program Get free € to redeem on your next order by buying these products. Discover the Brildor Loyalty Program



Trial version

Supported printers

Installation requirements

What's in the dongle?

Pre-production tool

Colour and ink management tool

License extension for up to 3 printers



  • Ultra-fast RIP processing, even with multiple job queues, which you can configure according to the printer, inks and layouts.
  • Compatible with modified Epson L1800 and L805 printers included in our DTF printer bundles (A4 and A3 sizes)
  • Maximum optimisation of printer and ink efficiency
  • Very simple, user-friendly interface with quick responsiveness
  • Includes CMYK + White drivers, specially created for L1800 and L805 printers
  • Real-time nozzle check, automatic print head cleaning, and maintenance alert notifications
  • Several preview modes: white layer (choke), colour layer, colour replacement, final result, print preview
  • Pre-set print modes with the possibility to manually adjust the parameters by creating a template




For CadLink software to run properly, the computer must have the following characteristics:

  • Windows 7 SP1/8.1/10 operating system. All updates must be installed.
  • CPU: Intel Core i5-i 2.6-3.0 GHz
  • RAM: 8-12 GB
  • HARD-DRIVE: 500 GB SSD (recommended) or HDD
  • Maximum resolution: 1280 x 800 pixels
  • Recommended requirements: Windows 10 (64-bit) and 1600 x 90 pixels

(*) If any problems arise during the installation, we recommend turning off your antivirus protection.


  • Licence files (xxxxxxHM), where x is the dongle number
  • Program files (Digital Factory v10)
  • Quick setup sheet in PDF
  • Setup wizard link (setup.exe)

To install the software, connect the USB to the computer, run Setup.exe and follow the on-screen instructions.


  • Supports countless vector and pixel file formats such as bmp, gif, jpg, jpeg, png, ping, tif, tiff, psd, svg, ps, tmp, eps, ai and pdf
  • Image editing through GIMP, a free software similar to Photoshop and optimised to interact comfortably with the RIP without leaving the programme
  • Create patterns based on images to achieve full-print personalisation
  • You may arrange your designs manually or automatically on the same page, featuring the ability to copy the same design for a customisation run. It will generate copies of it in matrix mode using rows and columns to fill the film area
  • Automatic nesting of different layouts on the film Smart distribution of images for space optimisation
  • Super Size Image: increases the resolution to avoid visible pixels in non-vector images
  • You can use effects to add frames or vintage finishes


  • Quick adjustments for transparency, contrast, brightness, and saturation
  • Create patterns to reduce ink consumption
  • KnockMeBlackOut: for designs to be printed on black garments Eliminates black areas of the design, so that the white layer will not be printed followed by a layer of black, which saves ink
  • KnockMeColorOut: allows you to select and remove up to 4 colours from the design with a single click
  • White and colour ink flow control to optimise consumption and calculate cost per print


  • The CADlink software licence allows you to work with only one printing device. This extension allows you to add 3 printing devices with sheet formats up to A2 and rolls up to 43.2 cm wide
  • You can switch from one device to another without losing the configuration of each printer
  • You will receive an email with all the steps to install the extension before the delivery deadline
