Neon & White Blockout Flock HTV - Tubitherm by Poli-Tape

Rayon flock heat transfer vinyl in neon and white. The white vinyl has a blockout interlayer to prevent the colour of the fabric from "sublimating" and contaminating the colour of the vinyl.

  • 500 μ velvety surface
  • Not suitable for textiles with a hydrophobic impregnation
  • Sale units: 1 and 10 m rolls, 25 cm or 50 cm wide

More information

Availability:
Shown on each product
Reward Points
Get free € to redeem on your next order by buying these products. Discover the Brildor Loyalty Program Get free € to redeem on your next order by buying these products. Discover the Brildor Loyalty Program

More information about the Neon & White Blockout Flock HTV - Tubitherm by Poli-Tape



INDEX

> Description

> Colour reference list

> Technical characteristics

> Transfer parameters

> Application instructions

> Wash resistance

> Weight

> Colour card

> Data sheets

> Safety data sheet



DESCRIPTION

TUBITHERM neon-coloured vinyls are a PA (polyamide) film for textile transfer. The white blockout vinyl is a viscose film offering high opacity and sublimation resistance.

  • Excellent weeding and cutting. The material will not tear if the vinyl is quickly weeded
  • The liner is a self-adhesive PET (polyester) film that acts as a carrier
  • The 10-metre rolls have a Ø7.5 cm cardboard core
  • The raw materials are ecologically inert, do not contain PVC, plasticizers or heavy metals and are certified in accordance with Oeko-Tex Standard 100 Class I
  • Made in Germany by Poli-Tape



COLOUR REFERENCE LIST

Find Pantone, HEX, RGB, CMYK and RAL equivalents:

Colour reference list Tubitherm (.pdf - 0,51 MB)



TECHNICAL CHARACTERISTICS

Vinyl Polyamide (neon)
Viscose (Blockout)
Thickness (µ) 500
Support or liner PET film
Includes transporter Yes
Fabrics Polyester, cotton, cotton-polyester and polyester-acrylic blends
Cutting blade for vinyl cutter 60º
Laser cutting Yes
Blockout(*) Yes, white blockout vinyl only
Discard Hot/Tibium

(*) Prevents the colour of the textile from transferring to the vinyl during its application



TRANSFER PARAMETERS

  • Knife blade: 60º
  • Temperature: 160ºC
  • Time: 15 seconds
  • Pressure: 2.0 bar [medium pressure]



APPLICATION INSTRUCTIONS

  • Cut your design in mirror image with a cutter plotter
  • Weed out your vinyl excess
  • Preheat the press to 160ºC
  • Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
  • Position the vinyl over the garment and cover with protective paper
  • Press for 15 seconds, medium pressure
  • Warm peel the liner



WASH RESISTANCE

  • Washing resistance: 40 ºC max
  • Wash inside out
  • Suitable for tumble drying and dry cleaning



Weight

Roll (cm/m) 25 x 1 50 x 1 50 x 10
Weight (kg) 0.106 0.22 2.5



COLOUR CARD

Colour card for Tubitherm HTV (.pdf - 857 kB)



DATA SHEETS

Data sheet for Tubitherm HTV (.pdf - 636 kB)

Data sheet for Tubitherm Blockout White HTV (.pdf - 638 kB)



SAFETY DATA SHEET

When used under normal conditions, this product does not generate or release any dangerous substances or hazardous chemicals. This is a non-hazardous product in accordance with the current GefStoffV and EU criteria. Therefore it is not necessary to prepare a Material Safety Data Sheet for this product. The Safety Data Sheet serves only to comply with the regulation to supply information in accordance with REACH Regulation (EC) No. 1907/2006 and is available on request. This is not a hazardous product with regards to transportation legislation; neither does it contain substances that are hazardous to water within the meaning of the federal water act. After use, dispose of the waste product in accordance with the local / national authorities.
