€389.00 VAT not included / Each Unit

Shin Pad Heat Press Machine - Brildor SC-1.1

Name: Shin Pad Heat Press Machine - Brildor SC-1.1
SKU: 045087
Price: 389 EUR
Availability: InStock

Ref.

045087

Swing away heat press to customise shin guards using dye sublimation printing, transfer, vinyl and other techniques.

Manual opening and closing
Automatic timer
Heating plate dimensions: 24 x 22.5 cm

More information

Availability:

Immediate: 4 units

€389.00 VAT not included / Each Unit

VAT not included

Skip to the end of the images gallery

Skip to the beginning of the images gallery

More information about the Brildor SC-1.1 shin pad heat press machine

INDEX

DESCRIPTION

Suitable for sublimating all our shin guards for any sport like football, hockey, skateboarding and more. Different sizes available Related Products
Automatic timer with magnet-shaped detector that activates when the heat platen is placed over the shin pad
Pressure adjustment knob
Cooling fan that automatically activates when the press reaches 80ºC
Energy-saving system. The heating plate will automatically cool down if the press remains idle for more than 30 minutes
Base with suction cups to prevent it from moving. It also has 2 adjustment back supports for extra stability
RoHS CE mark

USER MANUAL

User Manual Brildor SC-1.1 Shin Pad Press Machine (.pdf - 1.40 MB)

TECHNICAL DETAILS

Press model	Brildor SC-1.1
Press type	Manual/Swing Away/Shin Pad
Controller	LCD digital display
Pad thickness	0.8 cm
Side opening angle	180º
Voltage	220 V / 50 Hz
Power	450 W / 2 A
Timer	0-999 s
Temperature range	0-221ºC
Temperature accuracy	±2ºC
Time before Sleep Mode	30 min

PRESS DIMENSIONS

Press closed in its initial position	31 x 51 x 37 cm
Closed press with additional legs extended	45 x 51 x 37 cm
Press with the heat platen to the side	47 x 53 x 37 cm
Lower platen	19.5 x 20.5 x 8 cm
Heating plate	24 x 22.5 x 8 cm
Power cable	151.5 cm
Packaging	46.5 x 43 x 34.5 cm
Net weight	10 kg

Additional Information

More Information
Ref.	045087
Gross Weight (kg)	10
Billable Weight (kg)	11.0000
Power (W)	450
Pressure regulation	Manual
Opening	Manual
Closing	Manual
