SUBLITEX is a thermo-adhesivepolyester film for heat textile transfer on light and dark fabrics.
Printable on its rough side
Denim-like finish
Thick, full-bodied vinyl. Can be cut with a vinyl cutter, scissors or a cutter
Oeko-Tex Standard 100 Class I certifies that it is suitable for application on baby and children's clothing
The liner is a clear self-adhesive polyester film
Made in France by Chemica
THINGS TO KEEP IN MIND
Not suitable for Epson SC-F100 and SC-F500 printers
For small designs with a lot of detail, use transfer tape for easier vinyl application. In this case, we recommend using a high tack application tape such as Poli-Tack 850
When using a transfer tape, you must remember that, since it is made of polyester, some of the ink may remain on it due to resublimation. To avoid this, we recommend pressing it for a short time (2-3 seconds), removing the carrier from the vinyl, and pressing it again
After printing the vinyl with ink, it should be left to dry. Transfer it to the garment once the ink is dry to the touch
Print it using cut marks to cut it with the plotter
Wait at least 24 hours before the first wash
SUBLIMATION INK PARAMETERS
Knife blade: 60º
Temperature: 170 °C
Pressure: 2.5 - 3.0 bar [medium pressure]
Time: 50 seconds
SOLVENT AND ECO-SOLVENT PARAMETERS
Knife blade: 60º
Temperature: 160 °C
Pressure: 2.5 - 3.0 bar [medium pressure]
Time: 20 seconds
APPLICATION INSTRUCTIONS FOR SUBLIMATION INKS
Print the design directly on the rough side of the vinyl
Let the ink dry
Cut the vinyl with a plotter when the ink is dry to the touch.
Weed out your excess vinyl
In case of using an application tape, stick it to the vinyl starting from the centre outwards, avoiding creasing the vinyl
Preheat the press to 170ºC
Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
Take the vinyl off its liner and place it on the garment
Cover with protective paper
Press for 50 seconds, medium pressure
If you have used transfer tape, hot peel it
APPLICATION INSTRUCTIONS FOR SOLVENT AND ECO-SOLVENT INKS
Print the design directly on the rough side of the vinyl
Cut it with a plotter or scissors
Weed out your excess vinyl
In case of using an application tape, stick it to the vinyl starting from the centre outwards, avoiding creasing the vinyl
Preheat the press to 160ºC
Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
Take the vinyl off its liner and place it on the garment
