LIBERTY SUBLI PRINT is a sublimation thermo-adhesivepolyester film for heat textile transfer on light and dark fabrics.
Printable on the matte textured side
Can be applied with a heat press or domestic iron
Can be cut with a cutting machine, scissors or cutter
Thin and elastic
Oeko-Tex Standard 100 class I certifies that the raw materials used are environmentally friendly, free of PVC, solvents, plasticisers and heavy metals
Made in Germain by Poli-Tape
THINGS TO KEEP IN MIND
For small or detailed designs, it may be convenient to use application tape suitable for this vinyl
After printing the vinyl, it should be left to dry. Transfer it to the garment once the ink is dry to the touch
If you are using an Epson SC-F100 or SC-F500 printer, it can leave ink smudges. To avoid this, print unidirectionally, with standard quality and lower the density by 10-30%
For nylon fabrics it is advisable to carry out tests
TECHNICAL DETAILS
VINYL
Outside layer
Printable thermo adhesive copolymer
Inside layer
White water-based polyurethane
Thickness (μ)
150
Carrier (μ)
Self-adhesive polyester 120
CARRIER
Tack
HIGH
Thickness (μ)
90
Material
Polyester PET film
Colour
Clear
Surface
Dotted texture
TRANSFER PARAMETERS
COTTON, POLYESTER AND COTTON BLEND FABRICS
Temperature: 140 °C
Pressure: 3.0 bar [medium-high pressure]
Time: 15 seconds
Pre-pressing of the garment: 140-150ºC, 4-5 seconds
NYLON
Temperature: 150 °C
Pressure: 3.0 bar [medium-high pressure]
Time: 20 seconds
Pre-pressing of the garment: 140-150ºC, 4-5 seconds
APPLICATION INSTRUCTIONS
COTTON, POLYESTER AND COTTON BLEND FABRICS
Print the design directly on the rough side of the vinyl in direct mode
Let the ink dry
Cut the vinyl with a plotter when the ink is dry to the touch
Weed out your excess vinyl
Preheat the press to 140ºC
Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture
Position the vinyl over the garment and cover it with protective paper
Press for 15 seconds, medium pressure
Hot peel the liner
NYLON
Print the design directly on the rough side of the vinyl in direct mode
Let the ink dry
Cut the vinyl with a plotter when the ink is dry to the touch
Weed out your excess vinyl
Preheat the press to 150ºC
Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
Position the vinyl over the garment and cover it with protective paper
Press for 20 seconds, medium pressure
Hot peel the liner
WASH RESISTANCE
Wait 48 hours before the first wash
Washing resistance: 30 ºC max
Wash inside out
Avoid the use of aggressive detergents
Iron inside out
STORAGE RECOMMENDATIONS
Store in a warm, dry place away from direct sunlight
