Sublimatable Matt Aluminium Photo Panels
Photographic panels of aluminium 1 mm, customisable by dye sublimation printing.
Transfers with high photographic resolution
- Rounded corners
- Can be cut and perforated
More information
Our availability is not enough?
Let us know how much you need
I WANT MORE
More information about the Sublimatable Matt Aluminium Photo Panels
INDEX
> Description
> Things to keep in mind
> Measurements
> Recommended Sublimation Instructions and Parameters
DESCRIPTION
- High-quality aluminium photopanels: thin and lightweight
- Matte white side is sublimable. Silver-coloured reverse
- Rounded corners with a radius of 1.5 mm
- Can be customised in either vertical or horizontal orientation
THINGS TO KEEP IN MIND
- Do not include profiles or supports. See some options in Related Products
- The sublimable white side has a transparent plastic film that must be removed before customising the photopanels
MEASUREMENTS
| Reference |
054089 |
054087 |
054076 |
054077 |
054088 |
054078 |
054079 |
054081 |
054082 |
054083 |
| Panel (cm) |
10.1 x 10.1 |
15.2 x 15.2 |
8.9 x 12.7 |
10 x 15 |
15.2 x 20.3 |
18 x 27 |
20.3 x 25.4 |
20.3 x 30.5 |
30 x 40 |
40 x 60 |
| Digital format |
1:1 |
1:1 |
- |
3:2 |
4:3 |
3:2 |
4:5 |
2:3 |
3:4 |
2:3 |
| Thickness (mm) |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
RECOMMENDED SUBLIMATION INSTRUCTIONS AND PARAMETERS
Parameters indicated are for guidance only. It is recommended to conduct preliminary tests to make necessary adjustments before starting production.
- Print the design in mirror mode
- Heat the press to 200°C
- Place the panel on the press and the printed design on the panel. Secure them with heat-resistant adhesive tape
- Close the press with medium pressure for 60 seconds
- Using a protective glove, remove the newly sublimated panel
- Carefully remove the paper
More Information
| Ref. |
952013 |
| Thickness (mm) |
1 |
| Colour |
White |
| Surface material |
Aluminium |
| Items |
Photo panels |
| Marking techniques |
Dye sublimation |
