Spare Parts for Brildor A3.2 Heat Presses

Be the first to review this product

Spare Parts for Brildor A3.2 Heat Presses

Be the first to review this product

Spare parts for the Brildor A3.2 heat presses (Ref. 028050, Ref. 009523, Ref. 034617).

More information

Get free € to redeem on your next order by buying these products. Discover the Brildor Loyalty Program

More information about the spare parts for the Brildor A3.2 heat presses

INDEX

> Description of spare parts

> Compatibility chart

> Warranty

DESCRIPTION OF SPARE PARTS

GY-04 Control Board

Ref. 029419

Digital time and temperature controller. Time range: 0-999s Temperature range: 0-225ºC / 0-437ºF

Power supply board

Ref. 029417

Compatible with UH3.2 and discontinued models (Magnetic Star, A3 and MAX series).

Central Shock Absorber (120 kg)

Ref. 034145

Reference no 0010-12 120 kg. Dimensions: Ø3 x 26 cm

DGGY31 Shock Absorber (5 kg)

Ref. 046723

Suitable for 40 x 50 cm Brildor A3.2 heat presses (Ref. 009523). Dimensions Ø2 x 54.5 cm

Cooling Fan

Ref. 035462

Dimensions: 9.2 x 9.2 x 2.5 cm

3-Phase 100A Relay

Ref. 037045

Suitable for 80 x 50 cm Brildor A3.2 heat presses (Ref. 034617). Dimensions: 10.5 x 7.5 x 3.8 cm

Transformer

Ref. 033068

Original electronic component. Dimensions: 6 x 94 x 6 cm

Thermostat Switch

Ref. 042268

Metal piece.

Screw to Move the Upper Plate

Ref. 035238

Ball screw for the movement mechanism of the top plate of the Brildor A3.2 heat press. Dimensions Ø1.8 x 5 cm

COMPATIBILITY CHART

Spare Part	Spare Part Reference	Spare Part Heat Press (cm)
		028050 (38 x 38)	009523 (40 x 50)	034617 (80 x 50)
Control Board	029419	✔	✔	✔
Central Shock Absorber	034145	✔	✔	✔
DGGY31 Shock Absorber (5 kg)	046723	✗	✔	✗
Cooling Fan	035462	✔	✔	✔
3-Phase 100A Relay	037045	✗	✗	✔
Transformer	033068	✔	✔	✔
Thermostat Switch	042268	✔	✔	✔
Screw to move the upper plate	035238	✔	✔	✔

WARRANTY

Spare parts: 3 months

The warranty period starts from the date mentioned on the invoice of purchase.

Additional Information

Ref.	948873

Reviews

Share your opinion

It will only take a minute, and your opinion can help other customers.

0 reviews

Questions

No questions found for this product.

Be the first to ask a question!
