Suitable for any heat transfer personalisation technique: sublimation, transfer, vinyl, DTF and more
One-touch automatic closing and opening system
Adjustment knob to turn it on/off, setting the press or to close and open it
Reaches the desired temperature quickly
Automatic pressure adjustment
Includes pad made of flame-retardant polyester fabric with non-slip base for the lower platen. Prevents the item to be personalised from moving, protects the platen and eliminates humidity
Auto shut-off after 2h of inactivity
Ceramic-coated heat plate
Push button on the top of the press to open and close it, you can also press the adjustment wheel
Made of sturdy steel with a plastic casing that does not burn when touched
Although it is suitable for DTF, it is not suitable for film curing. This is because the pressure adjustment is done automatically, making it impossible to adjust the height
The heating plate is slightly smaller than the platen
Timer is activated when the press is closed by pressing the adjustment knob
Push button on the top of the press with light so you know when it’s ready to be used
WHAT DOES THIS PRESS INCLUDE?
1
Anti-slip pad
1
Adjustment knob with USB cable
1
User manual
INSTRUCTIONS FOR USE
Connect the press to the mains
Plug the USB cable from the panel into the back of the press
Press the power button on the control wheel to turn on the press
It will automatically open and start to heat up
Adjust the time and temperature. If you need help you can refer to the manual
Place the pressing mat on the lower platen and then the object
Apply the vinyl, transfer paper or design you want to transfer
Wait for the press to heat up
Set the correct time and temperature settings for the material you want to personalise
Wait for the orange light to turn green
Press the push button or the control wheel to close the press and start the timer
The press will auto-release when the pressing time is up
To turn off the machine, hold press the power button for 3 seconds
PRINT AREA TEMPLATE
To make it easier for you, we have provided the following template with the maximum print area of the press. To see the layers of the template, open the PDF file using Photoshop:
https://www.brildor.com/en/plancha-transfer-automatica-elite-auto-heat-press51179Elite Auto Heat Press<p class="enlace"><a id="know-more"></a> </p>
<h2>More information about the Elite Auto Heat Press</h2>
<p> </p>
<p><strong>INDEX</strong></p>
<p>> <a href="#know-more1">Description</a></p>
<p>> <a href="#know-more2">User manual</a></p>
<p>> <a href="#know-more3">Things to keep in mind</a></p>
<p>> <a href="#know-more4">What does this press include?</a></p>
<p>> <a href="#know-more5">Instructions for use</a></p>
<p>> <a href="#know-more6">Print area template</a></p>
<p>> <a href="#know-more7">Technical details</a></p>
<p>> <a href="#know-more8">Press dimensions</a></p>
<p> </p>
<p class="enlace"><a id="know-more1"></a> </p>
<p><strong>DESCRIPTION</strong></p>
<ul>
<li>Suitable for any <span class="azul-brildor-negrita">heat transfer</span> personalisation technique: <span class="azul-brildor-negrita">sublimation</span>, <span class="azul-brildor-negrita">transfer</span>,<span class="azul-brildor-negrita"> vinyl</span>,<span class="azul-brildor-negrita"> DTF</span> and more</li>
<li>One-touch automatic closing and opening system</li>
<li>Adjustment knob to turn it on/off, setting the press or to close and open it</li>
<li>Reaches the desired temperature quickly</li>
<li>Automatic pressure adjustment</li>
<li>Includes pad made of flame-retardant polyester fabric with non-slip base for the lower platen. Prevents the item to be personalised from moving, protects the platen and eliminates humidity</li>
<li>Auto shut-off after <span class="azul-negrita">2h</span> of inactivity</li>
<li>Ceramic-coated heat plate</li>
<li>Push button on the top of the press to open and close it, you can also press the adjustment wheel</li>
<li>Made of sturdy steel with a plastic casing that does not burn when touched</li>
<li>CE certificate for European conformity</li>
<li><strong>Warranty:</strong> 3 years against manufacturing defects</li>
</ul>
<p> </p>
<p class="enlace"><a id="know-more2"></a> </p>
<p><strong>USER MANUAL<br></strong></p>
<p><a title="User manual Elite Auto Heat Press (.pdf - 0.79 MB)" href="https://www.brildor.com/media/upload/descargas/Auto_Heat_Press_Craft_Express_User_Manual_EN.pdf" target="_blank" rel="nofollow noopener">User manual Elite Auto Heat Press (.pdf - 0.75 MB)</a></p>
<p> </p>
<p class="enlace"><a id="know-more3"></a> </p>
<p><strong>THINGS TO KEEP IN MIND</strong></p>
<ul>
<li>Although it is suitable for <span class="azul-brildor-negrita">DTF</span>, it is not suitable for <strong>film curing</strong>. This is because the pressure adjustment is done automatically, making it impossible to adjust the height</li>
<li>The heating plate is slightly smaller than the platen</li>
<li>Timer is activated when the press is closed by pressing the adjustment knob</li>
<li>Push button on the top of the press with light so you know when it’s ready to be used</li>
</ul>
<p> </p>
<p class="enlace"><a id="know-more4"></a> </p>
<p><strong>WHAT DOES THIS PRESS INCLUDE?</strong></p>
<table>
<tbody>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>Anti-slip pad</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>Adjustment knob with USB cable</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>User manual</td>
</tr>
</tbody>
</table>
<p> </p>
<p class="enlace"><a id="know-more5"></a> </p>
<p><strong>INSTRUCTIONS FOR USE</strong></p>
<ol>
<li>Connect the press to the mains</li>
<li>Plug the USB cable from the panel into the back of the press </li>
<li>Press the power button on the control wheel to turn on the press</li>
<li>It will automatically open and start to heat up</li>
<li>Adjust the time and temperature. If you need help you can refer to the <a href="https://www.brildor.com/media/upload/descargas/Auto_Heat_Press_Craft_Express_User_Manual_EN.pdf" target="_blank" rel="nofollow noopener">manual</a></li>
<li>Place the pressing mat on the lower platen and then the object</li>
<li>Apply the vinyl, transfer paper or design you want to transfer</li>
<li>Wait for the press to heat up</li>
<li>Set the correct time and temperature settings for the material you want to personalise</li>
<li>Wait for the orange light to turn green</li>
<li>Press the push button or the control wheel to close the press and start the timer</li>
<li>The press will auto-release when the pressing time is up</li>
<li>To turn off the machine, hold press the power button for <span class="azul-negrita">3 seconds</span></li>
</ol>
<p> </p>
<p class="enlace"><a id="know-more6"></a> </p>
<p><strong>PRINT AREA TEMPLATE<br></strong></p>
<p>To make it easier for you, we have provided the following template with the <strong>maximum print area</strong> of the press. To see the layers of the template, open the PDF file using Photoshop:</p>
<ul>
<li><a title="Print area template Elite Auto Heat Press" href="https://www.brildor.com/media/upload/descargas/Plantilla_Area_Impresion_Plancha_Transfer_Cricut_AutoPress.pdf" target="_blank" rel="nofollow noopener">Print area template Elite Auto Heat Press (.pdf - 0.66 Mo)</a></li>
</ul>
<p> </p>
<p class="enlace"><a id="know-more7"></a> </p>
<p><strong>TECHNICAL DETAILS<br></strong></p>
<table>
<tbody>
<tr>
<td><strong>Press model</strong></td>
<td>Elite Auto Heat Press</td>
</tr>
<tr>
<td><strong>Press type</strong></td>
<td>Clam</td>
</tr>
<tr>
<td><strong>Lower platen type</strong></td>
<td>Fixed</td>
</tr>
<tr>
<td><strong>Controller</strong></td>
<td>Digital display</td>
</tr>
<tr>
<td><strong>Lower platen dimensions(cm)</strong></td>
<td><span class="azul-negrita">39.5 x 32</span></td>
</tr>
<tr>
<td><strong>Heat plate dimensions (cm)</strong></td>
<td><span class="azul-negrita">38 x 30.5</span></td>
</tr>
<tr>
<td><strong>Maximum print area (cm)</strong></td>
<td><span class="azul-negrita">38 x 30.5<br></span></td>
</tr>
<tr>
<td><strong>Maximum opening angle</strong></td>
<td><span class="azul-negrita">45º</span></td>
</tr>
<tr>
<td><strong>Temperature range (ºC | ºF)<br></strong></td>
<td><span class="azul-negrita">40 - 210</span> | <span class="azul-negrita">104 - 410</span></td>
</tr>
<tr>
<td><strong>Time range (s)</strong></td>
<td><span class="azul-negrita">0 - 999</span></td>
</tr>
<tr>
<td><strong>Power (W)</strong></td>
<td><span class="azul-negrita">800</span></td>
</tr>
<tr>
<td><strong>Voltage (V | Hz)</strong></td>
<td><span class="azul-negrita">220 | 60</span></td>
</tr>
<tr>
<td><strong>Press dimensions (cm)</strong></td>
<td><span class="azul-negrita">52.5 x 42 x 20.5</span></td>
</tr>
<tr>
<td><strong>Packaging (cm)</strong></td>
<td><span class="azul-negrita">58.5 x 48.5 x 28</span></td>
</tr>
<tr>
<td><strong>Net weight (kg)</strong></td>
<td><span class="azul-negrita">15.5</span></td>
</tr>
<tr>
<td><strong>Gross weight (kg)</strong></td>
<td><span class="azul-negrita">17.05</span></td>
</tr>
</tbody>
</table>
<p class="enlace"> </p>
<p> </p>
<div id="gtx-trans">
<div class="gtx-trans-icon"> </div>
</div>https://www.brildor.com/media/catalog/product/p/l/plancha-transfer-automatica-elite-auto-heat-press-d13.jpg299instock69529957396000https://www.brildor.com/media/catalog/product/p/l/plancha-transfer-automatica-elite-auto-heat-press-d13.jpg44843485215012654219/Heat Presses/Heat Presses/Heat Presses & Ovens/Clam Heat Presses/Heat Presses/Heat Presses & Ovens/Offers2023-11-20T06:44:43+0000
