More information about the DTF cleaning solution

INDEX

> Recommendations for the use of the DTF EPSON L1800 printer

> Bottle dimensions

> Safety data sheet

RECOMMENDATIONS FOR THE USE OF THE DTF EPSON L1800 PRINTER

Flushing consists of pouring the cleaning solution through the nozzles of the printhead to remove any clogging. This can be done in 2 ways:

Without removing the printhead

• Turn on the printer and when the printhead moves, unplug it
• Remove the screw and the printhead cover
• Place kitchen paper under the printhead. Make sure it is on top of the paper
• Take out the cartridges with the help of a flat screwdriver in the order they are in
• Now pour some liquid into a container and fill one of the syringes included with the DTF printing system
• Attach the hose to the nozzle and lightly inject the cleaning fluid
• Repeat the operation on the clogged nozzles
• Finally, put all the parts back in place

By disassembling the printhead

• Turn on the machine and turn it off when the head moves so that it can be released
• Take it to the working area and remove the cover
• Remove the dampers. Now free the right cover that holds the flex cables from the head using a screwdriver
• Take off the back piece. To do this, use a screwdriver and release the tabs located on each side.
• Finally, to release the head, unscrew the three remaining screws using a magnetic screwdriver
• Take out the head and place it upside down, taking special care not to touch the silver part or you will damage it
• Carefully release the flex cables all at once
• Use a cleaning swab to clean around the edge of the printhead, as it may contain dried ink
• Use a syringe to push cleaning fluid through each nozzle. Place a bucket or container underneath so you don't make a mess
• Do not push too hard. You will see some ink mist come out plus the cleaning fluid
• When finished, carefully reassemble the printhead and install the cables correctly
• Put the screws, the protectors and the dampers back in place

BOTTLE DIMENSIONS

SAFETY DATA SHEET

Safety data sheet of the DTF cleaning solution (.pdf - 0.341 MB)
