xTool M1 Diode Lasers Engraver and Vinyl Cutter
<p><a name="know-more"></a></p>
<h2>More information about the Laser Cutting and Engraving Machine with Diode and Plotter – xTool M1</h2>
<p> </p>
<p><strong>CONTENTS</strong></p>
<p>> <a href="#know-more1">Features</a></p>
<p>> <a href="#know-more2">What is included with the machine?</a></p>
<p>> <a href="#know-more3">Things to keep in mind</a></p>
<p>> <a href="#know-more4">Accessories</a></p>
<p>> <a href="#know-more5">What is included in the saving pack (Ref. 056362)?</a></p>
<p>> <a href="#know-more6">Accessory dimensions</a></p>
<p>> <a href="#know-more7">Support material</a></p>
<p>> <a href="#know-more8">Some materials that can be cut and engraved</a></p>
<p>> <a href="#know-more12">Warranty</a></p>
<p>> <a href="#know-more9">Technical specifications</a></p>
<p>> <a href="#know-more10">Related posts</a></p>
<p class="enlace"><a id="know-more1"></a> </p>
<p><strong>FEATURES</strong></p>
<ul>
<li><strong>Versatile:</strong> Hybrid machine with laser and plotter integrated into the same head. Allows you to work with 2 personalisation techniques in a single machine</li>
<li><strong>Compact desktop design:</strong> Small size and minimalist look. Perfect for use in a shop or workshop, in view of customers</li>
<li><strong>Cutting plotter:</strong> with 45º blade capable of cutting adhesive vinyl, textile, card, paper, etc. up to <span class="azul-negrita">1.5 mm</span> thick</li>
<li><strong>Magnetic blade holder:</strong> Easy to remove and place in the head for quick blade changes</li>
<li><strong>Precision with dual laser:</strong> Laser module that merges two beams into a single point for deep cuts and detailed engraving</li>
<li><strong>AI Focus technology:</strong> Automatically identifies the thickness and type of material. The focus is automatic and does not require manual adjustment of laser cutting or engraving parameters</li>
<li><strong>Batch production:</strong> The camera recognises the position of objects and processes them all at once, reducing working time</li>
<li><strong>16 MP HD camera:</strong> Provides real-time images of the object. Allows more precise placement of the design, achieving better results</li>
<li><strong>Easy-to-use software:</strong> XCS with integrated AI. Captures the design of any object placed inside the machine and imports it into the software</li>
<li><strong>Safe:</strong> The machine stops immediately if the lid is opened</li>
<li><strong>Lid with protective glass:</strong> Complies with Class I laser safety standards, blocking laser light during operation</li>
<li><strong>Triangular prism rods:</strong> Included to raise the material and reduce smoke stains during laser cutting</li>
<li><strong>Integrated air extraction system:</strong> Includes a fan that expels smoke through the extraction tube (included). The tube must be directed outside the room</li>
<li><strong>Status light indicator button:</strong> Notifies the progress of the machine, lid lock, connection status, etc.</li>
<li><strong>Connectivity:</strong> Wi-Fi connection, USB port, PC connection port</li>
<li><strong>CE marking:</strong> Label certifying that this machine meets all legal requirements for marketing within the European Union</li>
</ul>
<p class="enlace"><a id="know-more2"></a> </p>
<p><strong>WHAT IS INCLUDED WITH THE MACHINE?</strong></p>
<table>
<tbody>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>Blade holder</td>
</tr>
<tr>
<td><span class="azul-negrita">5</span></td>
<td>45º tungsten steel cutting blades</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>Low-tack cutting mat <span class="azul-negrita">32.5 x 42.5 cm</span> (blue)</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>High-tack cutting mat <span class="azul-negrita">32.5 x 42.5 cm</span> (pink)</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>Removable tray</td>
</tr>
<tr>
<td><span class="azul-negrita">10</span></td>
<td>Rods</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>Smoke extraction tube</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>Pack with sample material</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>Power cable</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>USB cable</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>User manual</td>
</tr>
</tbody>
</table>
<p class="enlace"><a id="know-more3"></a> </p>
<p><strong>THINGS TO KEEP IN MIND</strong></p>
<ul>
<li>Accessories are purchased separately, they are not included with the machine</li>
<li>The diode laser does not engrave on transparent, translucent, or light-coloured materials such as acrylics, glass, etc. For these materials, we recommend using a CO2 laser machine</li>
<li>It is not recommended to use blades from other brands</li>
</ul>
<p class="enlace"><a id="know-more4"></a> </p>
<p><strong>ACCESSORIES</strong></p>
<p><strong>xTool SafetyPro AP2 Air Purifier</strong></p>
<ul>
<li>Compact and efficient design: high-powered motor for particle and odour suction, with quiet operation (<span class="azul-negrita">55 dB</span>). Ideal for domestic and professional spaces without ventilation</li>
<li>Easy filter removal and replacement: design with removable magnetic door. Allows you to change filters without dismantling the machine</li>
<li>6-layer filtration system included:
<ul>
<li><strong>SuperCyclone:</strong> separates and captures large particles. Prevents filter blockages and extends filter life. Easy to clean and reusable (clean every 3 to 6 months)</li>
<li><strong>Pre-filter:</strong> traps dust and lint, preventing them from reaching higher efficiency filters (estimated lifespan <span class="azul-negrita">100 hours</span>)</li>
<li><strong>Medium efficiency filter:</strong> captures medium-sized particles, such as pollen and mould spores, improving air quality (estimated lifespan <span class="azul-negrita">200 hours</span>)</li>
<li><strong>Activated carbon layer:</strong> absorbs harmful gases (estimated lifespan <span class="azul-negrita">600 hours</span>)</li>
<li><strong>Ultra-dense carbon mesh:</strong> absorbs up to 97.97% of odours, improving air quality (estimated lifespan <span class="azul-negrita">300 hours</span>)</li>
<li><strong>HEPA filter:</strong> capable of trapping at least 99.97% of particles of <span class="azul-negrita">0.3 µm</span> or larger (estimated lifespan <span class="azul-negrita">300 hours</span>)</li>
</ul>
</li>
<li>Optimal filtration mode depending on the material</li>
<li>Automatic on/off via Bluetooth connection</li>
<li>Monitors filter usage in real time: allows you to view the lifespan of each filter and prevents premature replacement</li>
<li>Includes extraction tube, pipe connectors, and clamp</li>
</ul>
<p><strong>Riser base with honeycomb panel</strong></p>
<ul>
<li>Increases working height up to <span class="azul-negrita">120 mm</span></li>
<li>Features slots at different height levels to place the removable tray or panel</li>
<li>Easy to fit. Placed under the machine without dismantling</li>
<li>Required for use with the RA2 Pro accessory</li>
<li>Honeycomb panel included <span class="azul-negrita">31 x 43 x 2.3 cm</span>:
<ul>
<li>Structure allows air circulation, achieving clean cuts without smoke stains</li>
<li>Cuts and engraves objects larger than <span class="azul-negrita">15 mm</span> in size, without them falling into the tray or burning</li>
<li>Includes 4 magnetic pins to hold the material in place</li>
</ul>
</li>
</ul>
<p><strong>RA2 Pro rotary accessory</strong></p>
<ul>
<li>Allows engraving of spherical and cylindrical objects such as mugs, rings, bottles, etc. by rotating them precisely</li>
<li>Includes 4 different adapters for objects: roller, chuck, sphere, and ring rotation</li>
<li>Compatible with xTool S1, P2, F1, F1 Ultra, D1, and M1 machines</li>
<li>2 cables to connect to xTool machines. Use the one compatible with your model</li>
<li>Requires the riser base for use</li>
</ul>
<p><strong>RA2 Pro rotary accessory kit</strong></p>
<ul>
<li>Expands the capabilities of the RA2 Pro rotary accessory:
<ul>
<li>Precise focus: the laser level marks the central axis of the piece held by the RA2 Pro, improving engraving results</li>
<li>Engraves in different positions: allows you to tilt the object held by the RA2 Pro up to <span class="azul-negrita">26º</span>. Achieve perfect alignment on conical pieces, engrave inside rings, etc.</li>
<li>Batch production with guides: positions the rotary accessory in the same place to process objects multiple times. Avoids repositioning each time, saving time</li>
</ul>
</li>
<li>Easily installed onto the rotary accessory, no additional tools required</li>
</ul>
<p><strong>Compressed air pump<br /></strong></p>
<ul>
<li>Achieves cleaner, mark-free cuts by blowing an air flow of <span class="azul-negrita">25-30 L/min</span></li>
<li>Adjustable air volume as needed</li>
<li>Protects the laser lens, increasing its durability</li>
<li>Easy to install inside the machine</li>
<li>Contains a cotton filter that removes impurities in the air pump</li>
</ul>
<p><strong>Fire safety kit</strong></p>
<ul>
<li>Detects, alerts with an acoustic alarm, and extinguishes fire automatically</li>
<li>Cuts off electrical current to stop the machine. Then releases CO2 gas to put out the fire</li>
<li>Easy to install and use. Includes a user manual with detailed instructions</li>
<li>Works with 4 bottles of non-toxic, odourless CO2 gas included in the kit. Easily replaced after each use</li>
</ul>
<p class="enlace"><a id="know-more5"></a> </p>
<p><strong>WHAT IS INCLUDED IN THE SAVING PACK (REF. 056362)?</strong></p>
<table>
<tbody>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>xTool M1</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>SafetyPro AP2 with 6 filtration layers included</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1<br /></span></td>
<td>Blade holder</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">5</span></td>
<td>45º tungsten steel cutting blades<span class="azul-negrita"><br /></span></td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>Low-tack cutting mat <span class="azul-negrita">32.5 x 42.5 cm</span> (blue)</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>High-tack cutting mat <span class="azul-negrita">32.5 x 42.5 cm</span> (pink)</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1<br /></span></td>
<td>Removable tray</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">10<br /></span></td>
<td>Rods to prevent smoke stains in the tray</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>Smoke extraction tube</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1<br /></span></td>
<td>Pack with sample material</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>Power cable</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>USB cable</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>User manual</td>
</tr>
</tbody>
</table>
<p class="enlace"><a id="know-more6"></a> </p>
<p><strong>ACCESSORY DIMENSIONS</strong></p>
<table>
<tbody>
<tr>
<td><strong>Reference</strong></td>
<td style="text-align: center;"><strong><span class="item-sku">051395</span></strong></td>
<td style="text-align: center;"><strong>055777<span class="item-sku"><br /></span></strong></td>
<td style="text-align: center;"><strong>051399</strong></td>
<td style="text-align: center;"><strong>055178</strong></td>
<td style="text-align: center;"><strong>051396</strong></td>
<td style="text-align: center;"><strong>055033</strong></td>
</tr>
<tr>
<td><strong>Accessory</strong></td>
<td style="text-align: center;">Riser base</td>
<td style="text-align: center;">SafetyPro AP2 air filter</td>
<td style="text-align: center;">Rotary accessory</td>
<td style="text-align: center;">Rotary accessory kit</td>
<td style="text-align: center;">Air compressor</td>
<td style="text-align: center;">Fire safety kit</td>
</tr>
<tr>
<td><strong>Size (cm)</strong></td>
<td style="text-align: center;"><span class="azul-negrita">45 x 49 x 13.5</span></td>
<td style="text-align: center;"><span class="azul-negrita">29 x 49.1 x 54.2</span></td>
<td style="text-align: center;"><span class="azul-negrita">32 x 13.8 x 10.5</span></td>
<td style="text-align: center;"><span class="azul-negrita">26 x 16.5 x 10.5<br /></span></td>
<td style="text-align: center;"><span class="azul-negrita">12 x 12.7 x 6.15</span></td>
<td style="text-align: center;"><span class="azul-negrita">25 x 7.5 x 10.5</span></td>
</tr>
<tr>
<td><strong>Packing (cm)</strong></td>
<td style="text-align: center;"><span class="azul-negrita">35.5 x 53.5 x 15.5</span></td>
<td style="text-align: center;"><span class="azul-negrita">20.7</span></td>
<td style="text-align: center;"><span class="azul-negrita">47 x 19.5 x 10</span></td>
<td style="text-align: center;"><span class="azul-negrita">19.2 x 31.5 x 11.3<br /></span></td>
<td style="text-align: center;"><span class="azul-negrita">17 x 29 x 13.5</span></td>
<td style="text-align: center;"><span class="azul-negrita">40.5 x 11 x 33.5</span></td>
</tr>
<tr>
<td><strong>Net weight (kg)</strong></td>
<td style="text-align: center;"><span class="azul-negrita">5.3</span></td>
<td style="text-align: center;"><span class="azul-negrita">14</span></td>
<td style="text-align: center;"><span class="azul-negrita">2.6</span></td>
<td style="text-align: center;"><span class="azul-negrita">1.03<br /></span></td>
<td style="text-align: center;"><span class="azul-negrita">1.2</span></td>
<td style="text-align: center;"><span class="azul-negrita">0.91</span></td>
</tr>
</tbody>
</table>
<p class="enlace"><a id="know-more7"></a> </p>
<p><strong>SUPPORT MATERIAL</strong></p>
<ul>
<li>Scan the QR code you will receive with your equipment to access all the installation, usage, and maintenance material for this laser machine. Via the link, you can download instructions, manuals, and even tutorial videos</li>
</ul>
<p class="enlace"><a id="know-more8"></a> </p>
<p><strong>SOME MATERIALS THAT CAN BE ENGRAVED AND CUT WITH LASER OR BLADE<br /></strong></p>
<p>Information provided by the manufacturer for <strong>guidance purposes</strong>. It may vary depending on the composition of the material, so prior testing is recommended.</p>
<p>See <a href="https://support.xtool.com/article/1716#e35102c388a8064768c461508fdd6a400" target="_blank" rel="noopener">here</a> for all materials you can cut and engrave.</p>
<table>
<tbody>
<tr>
<td><strong>Material</strong></td>
<td style="text-align: center;"><strong>Laser engraving<br /></strong></td>
<td style="text-align: center;"><strong>Laser cutting<br /></strong></td>
<td style="text-align: center;"><strong>Blade cutting<br /></strong></td>
</tr>
<tr>
<td><strong>Wood</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>Some dark and opaque acrylics</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>Galvanised metal</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>Painted metal</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>Bamboo</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>Ceramic</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>Cement</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>Brick</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>MDF</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>Marble</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>Slate</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>Paper</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
</tr>
<tr>
<td><strong>Kraft paper</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
</tr>
<tr>
<td><strong>Corrugated paper</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
</tr>
<tr>
<td><strong>Adhesive paper</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
</tr>
<tr>
<td><strong>Card</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
</tr>
<tr>
<td><strong>Fabric</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>Felt</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
</tr>
<tr>
<td><strong>Leather</strong></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
</tr>
<tr>
<td><strong>PU transfer vinyl</strong></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
</tr>
<tr>
<td><strong>PVC sheets</strong></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
</tr>
<tr>
<td><strong>PVC heat transfer vinyl</strong></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
</tr>
<tr>
<td><strong>Self-adhesive PVC</strong></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="rojo-negrita">✗</span></td>
<td style="text-align: center;"><span class="verde-negrita">✔</span></td>
</tr>
</tbody>
</table>
<p class="enlace"><a id="know-more12"></a> </p>
<p><strong>WARRANTY</strong></p>
<ul>
<li>As stipulated by law in: <a href="https://www.brildor.com/en/general-terms-and-conditions-for-the-sale#warranty" target="_blank" rel="noopener">General Terms and Conditions for the Sale of Goods</a></li>
</ul>
<p class="enlace"><a id="know-more9"></a> </p>
<p><strong>TECHNICAL SPECIFICATIONS</strong></p>
<table>
<tbody>
<tr>
<td colspan="2"><strong>XTOOL M1 ULTRA – LASER CUTTING AND ENGRAVING MACHINE WITH DIODE AND PLOTTER</strong></td>
</tr>
<tr>
<td>
<p><strong>Laser type</strong></p>
</td>
<td>
<p>Diode</p>
</td>
</tr>
<tr>
<td>
<p><strong>Laser power (W)</strong></p>
</td>
<td>
<p><span class="azul-negrita">10</span></p>
</td>
</tr>
<tr>
<td>
<p><strong>Laser safety</strong></p>
</td>
<td>
<p>Class I</p>
</td>
</tr>
<tr>
<td>
<p><strong>Laser spot (mm)</strong></p>
</td>
<td>
<p><span class="azul-negrita">0.08 × 0.08</span></p>
</td>
</tr>
<tr>
<td>
<p><strong>Laser speed (mm/s)</strong></p>
</td>
<td>
<p><span class="azul-negrita">250</span> (bitmap) | <span class="azul-negrita">160</span> (vector)</p>
</td>
</tr>
<tr>
<td>
<p><strong>Movement precision (mm)</strong></p>
</td>
<td><span class="azul-negrita">0.01</span></td>
</tr>
<tr>
<td><strong>Wavelength (nm)</strong></td>
<td><span class="azul-negrita">455</span></td>
</tr>
<tr>
<td>
<p><strong>Max. material thickness (mm)</strong></p>
</td>
<td>
<p>up to <span class="azul-negrita">8</span></p>
</td>
</tr>
<tr>
<td>
<p><strong>Laser working area (cm)</strong></p>
</td>
<td>
<p><span class="azul-negrita">30 x 38.5</span></p>
</td>
</tr>
<tr>
<td>
<p><strong>Plotter working area (cm)</strong></p>
</td>
<td>
<p><span class="azul-negrita">30 x 36.5</span></p>
</td>
</tr>
<tr>
<td>
<p><strong>Max. working height</strong><br /><strong>(without riser base) (mm)</strong></p>
</td>
<td>
<p>up to <span class="azul-negrita">40</span></p>
</td>
</tr>
<tr>
<td>
<p><strong>Max. working height</strong><br /><strong>(with riser base) (mm)</strong></p>
</td>
<td>
<p>up to <span class="azul-negrita">120</span></p>
</td>
</tr>
<tr>
<td><strong>Blade (º)</strong></td>
<td>
<p><span class="azul-negrita">45</span></p>
</td>
</tr>
<tr>
<td>
<p><strong>Cutting force (gf)</strong></p>
</td>
<td>
<p><span class="azul-negrita">360</span></p>
</td>
</tr>
<tr>
<td>
<p><strong>Max. cutting thickness (mm)</strong></p>
</td>
<td>
<p><span class="azul-negrita">1.5</span></p>
</td>
</tr>
<tr>
<td><strong>Camera pixels (MP)</strong></td>
<td>
<p><span class="azul-negrita">16</span></p>
</td>
</tr>
<tr>
<td><strong>Voltage (V)</strong></td>
<td>
<p><span class="azul-negrita">120</span></p>
</td>
</tr>
<tr>
<td><strong>Noise level (dB)</strong></td>
<td>
<p><span class="azul-negrita"><60</span></p>
</td>
</tr>
<tr>
<td>
<p><strong>Connection</strong></p>
</td>
<td>Wi-Fi, USB</td>
</tr>
<tr>
<td>
<p><strong>File formats</strong></p>
</td>
<td>SVG, DXF, JPG, JPEG, PNG, BMP, TIF, CR2...</td>
</tr>
<tr>
<td>
<p><strong>Operating systems</strong><br /><strong>(Desktop | Mobile)</strong></p>
</td>
<td>Windows/macOS/Android/iOS</td>
</tr>
<tr>
<td>
<p><strong>Compatible software</strong></p>
</td>
<td>xTool Creative Space</td>
</tr>
<tr>
<td>
<p><strong>Machine (cm)</strong></p>
</td>
<td><span class="azul-negrita">45 x 56 x 23</span></td>
</tr>
<tr>
<td>
<p><strong>Packing (cm)<br /></strong></p>
</td>
<td><span class="azul-negrita">76.6 x 56.7 x 35.7<br /></span></td>
</tr>
<tr>
<td>
<p><strong>Net weight (kg)</strong></p>
</td>
<td><span class="azul-negrita">9.8</span></td>
</tr>
<tr>
<td>
<p><strong>Gross weight (kg)<br /></strong></p>
</td>
<td><span class="azul-negrita">18.3<br /></span></td>
</tr>
<tr>
<td colspan="2"><strong>XTOOL SAFETYPRO AP2 AIR PURIFIER FILTER</strong></td>
</tr>
<tr>
<td>
<p><strong>Pre-filtration system</strong></p>
</td>
<td>SuperCyclone</td>
</tr>
<tr>
<td>
<p><strong>Compatible xTool machines</strong></p>
</td>
<td>P2S, P2, S1, M1 Ultra, F1 Ultra, D1, M1</td>
</tr>
<tr>
<td>
<p><strong>Power (W)</strong></p>
</td>
<td><span class="azul-negrita">220</span></td>
</tr>
<tr>
<td>
<p><strong>Noise (dB)</strong></p>
</td>
<td><span class="azul-negrita">55</span></td>
</tr>
<tr>
<td>
<p><strong>Filter layers</strong></p>
</td>
<td><span class="azul-negrita">6</span></td>
</tr>
<tr>
<td>
<p><strong>Dimensions (cm)</strong></p>
</td>
<td><span class="azul-negrita">29 x 49.1 x 54.2</span></td>
</tr>
<tr>
<td>
<p><strong>Net weight (kg)</strong></p>
</td>
<td><span class="azul-negrita">20.7</span></td>
</tr>
</tbody>
</table>
<p class="enlace"><a id="know-more10"></a> </p>
<p><strong>RELATED POSTS</strong></p>
<p><a href="https://www.brildor.com/blog/es/materiales-maquina-laser-todo-necesitas-saber/" target="_blank" rel="noopener">Materials for your laser machine: Everything you need to know</a></p>
<p><a href="https://www.brildor.com/blog/es/elige-maquina-laser-xtool-perfecta-guia/" target="_blank" rel="noopener">Choose like an expert! Find your perfect xTool laser machine with this guide</a></p>
https://www.brildor.com/media/catalog/product/m/_/m_quina-corte-grabado-l_ser-diodo-10w-plotter-corte-xtool-m1-sus-accesorios-d1.jpg
1443.33
instock
0
1443.33
0
0
0
https://www.brildor.com/media/catalog/product/m/_/m_quina-corte-grabado-l_ser-diodo-10w-plotter-corte-xtool-m1-sus-accesorios-d1.jpg
23547
51904
53114
53203
53468
54063
/Laser
/Laser/Maquinaria
/Grabado
2024-08-26T07:47:15+0000
