€299.00 VAT not included / Each Unit

Sublimation Oven - iSmart - 40L

Ref.
038784

An oven specially designed for personalisation using sublimation printing. Can sublimate small and medium-sized objects with different shapes, even irregular ones, that can withstand up to 230 ºC.

  • Compact size with a large cavity inside, enough to print up to 6 mugs of 11oz at once.
  • With 6 heating tubes and a fan that distributes heat evenly, ensuring a better printing quality.
  • Includes two metal trays to insert the objects in the oven.

More information

Instructions for use

Availability:
Inmmediate: 0 units
Expected entries:

30/09/21: 50 units
23/10/21: 50 units
Reward Points
As a Premium Brildor Member, for each unit you buy, you will accumulate {{POINTS}} to redeem on your next order. Discover the Brildor Loyalty Program. For each unit you buy, you will accumulate {{POINTS}} to redeem on your next order. Discover the Brildor Loyalty Program.
€299.00 VAT not included / Each Unit

More information about the iSmart sublimation oven (40 L)

  • Suitable for items up to 18 cm upright.
  • Easy to use, very practical. Can be moved easily.
  • With a powerful heating element, capable of heating the oven in a short time.
  • Has a tempered glass window with double glazing, through which the products can be easily observed.
  • Digital control panel for temperature and time.
  • Smart sensor to detect temperature changes and readjust automatically.
  • Precise and reliable temperature control. With an alarm that notifies the end of the programmed sublimation time.
  • Between processes, it is recommended to leave the air running to help maintain oven temperature, reducing work time.

TECHNICAL DETAILS

Temperature range 60 - 230ºC
Time range 1 - 120 min
Power 1600 W + 400 W (2000 W)
Voltage AC 220 V/50 Hz
Maximum item height 18 cm (vertically)
Outer dimensions 46 x 40 x 43 cm
Inner dimensions
39 x 25 x 31 cm
Packaging dimensions 56.5 x 53.5 x 48 cm
Tray dimensions 390 x 290 x 5 mm
Net weight
11.2 kg

Instructions for the use of the iSmart sublimation oven (40 L)

DESCRIPTION OF THE CONTROL PANEL

  • Start/Stop: press to turn the oven ON or OFF.
  • Upper tube: press to turn ON the upper heating tubes.
  • Lower tube: press to turn ON the lower heating tubes.
  • Low temp/Dry: press to turn ON the low-temperature heating mode.
  • Hot air: press to turn ON or OFF the flow of hot air inside.
  • Light: press to turn the oven light ON or OFF.
  • To set the temperature and printing time, the "Upper/Lower tube" and "Start/Stop" buttons must be turned respectively.

OPERATION

  • Press the "Start/Stop" button to turn ON the oven.
  • Press the "Hot air" button to turn ON the inner fan.
  • Turn the "Upper tube/Lower tube" button to adjust the sublimation time.
  • Roll the "Start/ Stop" button to adjust the temperature.
  • Press the "Start/Stop" button again for the oven to start heating up.
  • Once the oven reaches the set temperature, the timer will start counting.
  • You will hear a beep when the oven finishes the sublimation process.
    More Information
    Ref. 038784
    Net Weight (kg) 11.2
    Gross Weight (kg) 15.3
    Billable Weight 36.2700
