The sublimatable side of the tokens and boards have a clear plastic protective film that needs to be removed before sublimating. The film on some pieces includes an additional layer of paper to further protect the surface. Easily removable
The edges of the boards and the game pieces may contain some residue from the laser cutting. It is recommended to clean them with a damp cloth before personalising
TIPS & TRICKS
Create matching games and jigsaw puzzles. Print the boards and the game pieces with cartoon characters, family members, celebrities and play with familiar faces
DIMENSIONS
BOARDS
Reference no.
Boards (cm)
Thickness (mm)
039216
26.5 x 26.5
3
039219
39 x 39
3
039220
20 x 20
3
039509
40 x 30
3
GAME PIECES
Reference no
Shape
Dimension (cm)
Jig (cm)
Quantity (pcs)
Thickness (mm)
039221
Round
Ø1,6
9 x 9
16
3
039223
Round
Ø1
5.3 x 5.3
16
3
039224
Round
Ø2,5
12.3 x 12.3
16
3
039268
Round
Ø3,5
18 x 18
16
3
039225
Rectangular
3 x 5
20 x 28
30
3
048330
Rectangular
3 x 5
-
10
3
RECOMMENDED INSTRUCTIONS AND PARAMETERS FOR SUBLIMATION PRINTING
Parameters are given for guidance only. It is recommended to carry out preliminary tests in order to make the necessary adjustments before starting production.
BOARDS
Print the design in mirror image
Preheat the press to 180ºC
Remove the protective film from the board
Place the board on the press' lower platen and the paper's printed side against it. Fix them with heat-resistant tape
Press for 80-100-120 seconds (depending on the board’s size), medium-heavy pressure
With the help of a protective glove, take out the finished sublimated board
Carefully peel off the paper
GAME PIECES
Print the design in mirror image
Preheat the press to 190ºC
Remove the protective film
Place the jig or the game pieces on the press' lower platen and the paper's printed side against any of them. Fix them with heat-resistant tape
Press for 50-60 seconds, medium pressure
Using a protective glove, remove the newly printed jig or game pieces
https://www.brildor.com/en/sublimation-game-boards-and-pieces26498Sublimation Game Boards & Pieces<p><a name="know-more1"></a></p>
<h2>More information about game boards and pieces for sublimation</h2>
<p> </p>
<p><strong>INDEX</strong></p>
<p>> <a href="#saber-mas1">Description</a></p>
<p>> <a href="#saber-mas2">Download here the templates for the jig and the boards</a></p>
<p>> <a href="#saber-mas3">Things to keep in mind</a></p>
<p>> <a href="#saber-mas4">Tips & tricks</a></p>
<p>> <a href="#saber-mas5">Dimensions</a></p>
<p>> <a href="#saber-mas5">Recommended instructions and parameters for sublimation printing</a></p>
<p> </p>
<p><a name="saber-mas1"></a></p>
<p><strong>DESCRIPTION</strong></p>
<ul>
<li>Perfect for board games such as Parcheesi, checkers, Game of the Goose, dominoes, Who's Who, memory or matching games, and many more</li>
<li>The game pieces can be personalised on their white side</li>
<li>Jig for easy personalisation of the pieces (except Ref. 048330 which comes without jig)</li>
<li>The rectangular pieces can be used as additional cards for the “Who’s Who?” board game (Ref. 039226) which you will find in <strong>Related Products</strong></li>
</ul>
<p> </p>
<p><a name="saber-mas2"></a></p>
<p><strong>DOWNLOAD HERE THE TEMPLATES FOR THE JIG AND THE BOARDS<br></strong></p>
<ul>
<li><a title="20 x 20 cm game board template" href="https://www.brildor.com/media/upload/descargas/Plantilla_Brildor_Tablero_Juegos_20x20cm.psd" target="_blank" rel="nofollow noopener">20 x 20 cm game board template (.psd - 1.6 MB)</a></li>
<li><a title="26.5 x 26.5 cm game board template" href="https://www.brildor.com/media/upload/descargas/Plantilla_Brildor_Tablero_Juegos_26,5x26,5cm.psd" target="_blank" rel="nofollow noopener">26.5 x 26.5 cm game board template (.psd - 3 MB)</a></li>
<li><a title="39 x 39 cm game board template" href="https://www.brildor.com/media/upload/descargas/Plantilla_Brildor_Tablero_Juegos_39x39cm.psd" target="_blank" rel="nofollow noopener">39 x 39 cm game board template (.psd - 6.27 MB)</a></li>
<li><a title="A4 jig template" href="https://www.brildor.com/media/upload/descargas/Plantilla_Brildor_Fichas_Juegos_Horma_A4.psd" target="_blank" rel="nofollow noopener">A4 jig template (.psd - 33 MB)</a></li>
</ul>
<p> </p>
<p><a name="saber-mas3"></a></p>
<p><strong>THINGS TO KEEP IN MIND</strong></p>
<ul>
<li>The sublimatable side of the tokens and boards have a clear plastic protective film that needs to be removed before sublimating. The film on some pieces includes an additional layer of paper to further protect the surface. Easily removable</li>
<li>The edges of the boards and the game pieces may contain some residue from the laser cutting. It is recommended to clean them with a damp cloth before personalising</li>
</ul>
<p> </p>
<p><a name="saber-mas4"></a></p>
<p><strong>TIPS & TRICKS</strong></p>
<ul>
<li>Create matching games and jigsaw puzzles. Print the boards and the game pieces with cartoon characters, family members, celebrities and play with familiar faces</li>
</ul>
<p> </p>
<p><a name="saber-mas5"></a></p>
<p><strong>DIMENSIONS<br></strong></p>
<p><strong>BOARDS</strong></p>
<table >
<tbody>
<tr >
<td style="text-align: center;"><strong>Reference no.</strong></td>
<td style="text-align: center;"><strong>Boards<br>(cm)<br></strong></td>
<td style="text-align: center;"><strong>Thickness<br>(mm)<br></strong></td>
</tr>
<tr >
<td style="text-align: center;"><strong>039216</strong></td>
<td class="azul-negrita" style="text-align: center;">26.5 x 26.5</td>
<td style="text-align: center;"><span class="azul-negrita">3<br></span></td>
</tr>
<tr >
<td style="text-align: center;"><strong>039219</strong></td>
<td class="azul-negrita" style="text-align: center;">39 x 39</td>
<td style="text-align: center;"><span class="azul-negrita">3<br></span></td>
</tr>
<tr >
<td style="text-align: center;"><strong>039220</strong></td>
<td class="azul-negrita" style="text-align: center;">20 x 20</td>
<td style="text-align: center;"><span class="azul-negrita">3<br></span></td>
</tr>
<tr >
<td style="text-align: center;"><strong>039509</strong></td>
<td style="text-align: center;"><span class="azul-negrita">40 x 30<br></span></td>
<td style="text-align: center;"><span class="azul-negrita">3<br></span></td>
</tr>
</tbody>
</table>
<p><strong>GAME PIECES<br></strong></p>
<table >
<tbody>
<tr >
<td style="text-align: center;"><strong>Reference no</strong></td>
<td style="text-align: center;"><strong>Shape<br></strong></td>
<td style="text-align: center;"><strong>Dimension</strong><br><strong>(cm)<br></strong></td>
<td style="text-align: center;"><strong>Jig<br>(cm)<br></strong></td>
<td style="text-align: center;"><strong>Quantity</strong><br><strong>(pcs)<br></strong></td>
<td style="text-align: center;"><strong>Thickness<br>(mm)<br></strong></td>
</tr>
<tr >
<td style="text-align: center;"><strong>039221</strong></td>
<td style="text-align: center;">Round</td>
<td style="text-align: center;"><span class="azul-negrita">Ø1,6</span></td>
<td class="azul-negrita" style="text-align: center;">9 x 9</td>
<td style="text-align: center;"><span class="azul-negrita">16</span></td>
<td style="text-align: center;"><span class="azul-negrita">3<br></span></td>
</tr>
<tr >
<td style="text-align: center;"><strong>039223</strong></td>
<td style="text-align: center;">Round</td>
<td style="text-align: center;"><span class="azul-negrita">Ø1</span></td>
<td class="azul-negrita" style="text-align: center;">5.3 x 5.3</td>
<td style="text-align: center;"><span class="azul-negrita">16</span></td>
<td style="text-align: center;"><span class="azul-negrita">3<br></span></td>
</tr>
<tr >
<td style="text-align: center;"><strong>039224</strong></td>
<td style="text-align: center;">Round</td>
<td style="text-align: center;"><span class="azul-negrita">Ø2,5</span></td>
<td class="azul-negrita" style="text-align: center;">12.3 x 12.3</td>
<td style="text-align: center;"><span class="azul-negrita">16</span></td>
<td style="text-align: center;"><span class="azul-negrita">3<br></span></td>
</tr>
<tr >
<td style="text-align: center;"><strong>039268</strong></td>
<td style="text-align: center;">Round</td>
<td style="text-align: center;"><span class="azul-negrita">Ø3,5</span></td>
<td class="azul-negrita" style="text-align: center;">18 x 18</td>
<td style="text-align: center;"><span class="azul-negrita">16</span></td>
<td style="text-align: center;"><span class="azul-negrita">3<br></span></td>
</tr>
<tr >
<td style="text-align: center;"><strong>039225</strong></td>
<td style="text-align: center;">Rectangular<span class="azul-negrita"><br></span></td>
<td style="text-align: center;"><span class="azul-negrita">3 x 5</span></td>
<td style="text-align: center;"><span class="azul-negrita">20 x 28<br></span></td>
<td style="text-align: center;"><span class="azul-negrita">30</span></td>
<td style="text-align: center;"><span class="azul-negrita">3<br></span></td>
</tr>
<tr >
<td style="text-align: center;"><strong>048330</strong></td>
<td style="text-align: center;">Rectangular</td>
<td style="text-align: center;"><span class="azul-negrita">3 x 5</span></td>
<td style="text-align: center;">-</td>
<td style="text-align: center;"><span class="azul-negrita">10</span></td>
<td style="text-align: center;"><span class="azul-negrita">3<br></span></td>
</tr>
</tbody>
</table>
<p> </p>
<p><a name="saber-mas6"></a></p>
<p><strong>RECOMMENDED INSTRUCTIONS AND PARAMETERS FOR SUBLIMATION PRINTING</strong></p>
<p>Parameters are given for <strong>guidance only</strong>. It is recommended to carry out preliminary tests in order to make the necessary adjustments before starting production.</p>
<p><strong>BOARDS</strong></p>
<ul>
<li>Print the design in <strong>mirror image</strong></li>
<li>Preheat the press to <span class="azul-negrita">180ºC</span></li>
<li>Remove the protective film from the board</li>
<li>Place the board on the press' lower platen and the paper's printed side against it. Fix them with heat-resistant tape</li>
<li>Press for <span class="azul-negrita">80-100-120 seconds</span> (depending on the board’s size), medium-heavy pressure</li>
<li>With the help of a protective glove, take out the finished sublimated board</li>
<li>Carefully peel off the paper</li>
</ul>
<p><strong>GAME PIECES<br></strong></p>
<ul>
<li>Print the design in <strong>mirror image</strong></li>
<li>Preheat the press to <span class="azul-negrita">190ºC</span></li>
<li>Remove the protective film</li>
<li>Place the jig or the game pieces on the press' lower platen and the paper's printed side against any of them. Fix them with heat-resistant tape</li>
<li>Press for <span class="azul-negrita">50-60 seconds</span>, medium pressure</li>
<li>Using a protective glove, remove the newly printed jig or game pieces</li>
<li>Carefully peel off the paper</li>
</ul>https://www.brildor.com/media/catalog/product/f/i/fichas-rectangulares-de-juegos-para-sublimaci_n-horma-a4-con-30-uds-d10.jpg19.9instock019.9000https://www.brildor.com/media/catalog/product/f/i/fichas-rectangulares-de-juegos-para-sublimaci_n-horma-a4-con-30-uds-d10.jpg17426208942291527425276192821848500/Blanks/Blanks/Jigsaw Puzzles & Games/Blanks/Father's Day/Blanks/Only at Brildor/Blanks/Father's Day/Much More2021-07-24T06:08:21+0000
