Rip Software CADlink Digital Factory v11 DTF Desktop Edition
Software Rip CADlink Digital Factory V11 specifically developed for DTF.
Total image control to optimise the process and achieve high-quality prints.
- For Windows 10 and 11
- Code-activated licences
- Compatible with Photoshop, Illustrator, and CorelDRAW
- Suitable for modified DTF printers
- Licence extensions for A2 Ref. 040631:
- For printing in larger formats (Ref. 049247)
- For use on 3 devices and managing prints up to 43.2 cm wide (Ref. 049247)
- You can also purchase the latest licence upgrade from v10 to v11 in code format

More information about the Rip CADlink Digital Factory v11 DTF Desktop Edition software
INDEX
> Colour and ink management tool
DESCRIPTION
- Ultra-fast RIP processing, even with multiple job queues, configurable according to printer, inks, designs…
- Compatible with duly modified Epson, xTool, Prestige, and ColorBoost printers, included in our DTF system in A4, A3, and A3+ formats
- Capability to work with multiple formats and print media
- Maximises printer and ink performance
- Very simple and intuitive interface with quick response
- Includes CMYK + White drivers
- Real-time report of nozzle status, automatic head cleaning scheduling, and maintenance alert notifications
- Multiple preview modes: white layer (choke), colour layer, colour replacement, final result, print preview
- Pre-configured print modes and the ability to manually adjust parameters by creating templates
THINGS TO KEEP IN MIND
- Returns are not accepted for this product as it is software activated via code
- The delivery note indicates the activation code for the licence
15-DAY TRIAL VERSION
COMPATIBLE PRINTERS
INSTALLATION REQUIREMENTS
For the CadLink software to function correctly, the computer must have the following specifications:
- Windows 10/11 operating system. All updates must be installed.
- Intel i5-i 2.6-3.0 GHz processor
- 8-12 GB RAM
- 500 GB SSD (recommended) or HDD
- Minimum resolution of 1280 x 800 dpi
- Recommended conditions: 64-bit Windows 10 and 1600 x 900 dpi
NOTE: If issues arise during the process, it is recommended to disable the antivirus during installation.
PRE-PRODUCTION TOOLS
- Compatibility with a multitude of vector and raster formats such as bmp, gif, jpg, jpeg, png, ping, tif, tiff, psd, svg, ps, tmp, eps, ai, pdf
- Image editing via GIMP, a free software similar to Photoshop, optimised for comfortable interaction with the RIP without leaving the program
- Creation of patterns from images to fully print customisation areas
- Manual or automatic distribution of designs on the same page with the ability to copy the same design for a customisation run. Generates design copies in matrix mode using rows and columns to fill the film area
- Automatic nesting of different designs on the film. Distributes images intelligently optimising space
- Super Size Image: increases image resolution to prevent pixelation in non-vector images
- Application of effects for vintage finishes or frame addition
COLOUR AND INK MANAGEMENT TOOLS
- Quick adjustments for transparency, contrast, brightness, and saturation
- Halftone design to reduce ink usage
- Knockmeblackout: configuration of designs to be printed on black garments. Removes black areas from the design, thus not printing the white layer and subsequently a black layer, saving ink
- Knockmecolorout: allows selection and removal of up to 4 colours from the design with a simple click
- Control of white and colour ink flow to optimise consumption and calculate printing cost
A2 LICENCE EXTENSIONS
Applicable to the licence for printers up to A2 format (Ref. 040631).
A2 or larger extension
- Allows printing in larger formats using a small device
3 printer extension
- The CADlink software licence allows working with only one printing device. This extension provides the option to add 3 printing devices with sheet formats up to A2 and roll up to 43.2 cm wide
- You can switch from one device to another without losing the configuration of each printer
- Before the delivery deadline, you will receive an email with all the steps you need to follow for the installation of the extension
LICENCE UPGRADE
- Whether you purchased the v10 licence in USB dongle format or activation code, you can acquire the v11 upgrade:
Ref. | 944108 |
---|
