Compatible Blade Holders and Blades - Mimaki Vinyl Cutter
Compatible Blade Holders and Blades - Mimaki Vinyl Cutter
Blades compatible with Mimaki cutting plotters and their blade holders.
Available for materials: thin (30º), standard (45º), and thick (60º)
More information
More information about the Compatible Blade Holders and Blades - Mimaki Vinyl Cutter
INDEX
> Description
> Things to keep in mind
> Recommendations
> Specifications
> Measurements
DESCRIPTION
- The cutting head of the blades is made of cemented carbide. This material provides high hardness and good wear resistance
THINGS TO KEEP IN MIND
- Ensure the blade is correctly fitted into the blade holder
- The greater the blade angle, the deeper it will penetrate vertically, allowing for cutting thicker materials
- The colour of the protective cap helps identify its angle: yellow for 30º, red for 45º, and blue for 60º
- Conduct preliminary tests on blade placement and adjustment before starting production
RECOMMENDATIONS
- Keep the blade and the inside of the blade holder clean. Accumulated debris inside can hinder rotation and affect the cutting process
- Make cuts with the appropriate depth. Avoid cutting the vinyl's carrier paper or liner
- If the blade is correctly adjusted, it will extend its service life
- Change the plotter's offset when using a different blade
SPECIFICATIONS
Reference
|
050426 |
050427 |
050428 |
Blades
|
30º |
45º |
60º |
| Application |
Thin materials and large designs |
Standard use |
Thick materials and small designs |
| Examples |
Window films |
Vinyl and transfer paper |
Flock, sandblast, cardboard or reflective materials |
| Offset (mm) |
0.25 |
0.25 |
0.25 |
MEASUREMENTS
| Blades (mm) |
Ø1.45 x 19 |
| Blade Holders (mm) |
Ø15.8 x 50
|
| Gross weight of blades (g) |
16 |
| Net weight of blades (g) |
2 |
| Gross weight of blade holders (g) |
16 |
| Net weight of blade holders (g) |
12 |
