FLEXCUT ATOMIC is a water-based PU (polyurethane) film for transferring your designs on fabrics without water-repellent impregnation.
With a built-in liner
The raw materials are ecologically inert, do not contain PVC, plasticizers or heavy metals and are certified in accordance with Oeko-Tex Standard 100 Class II
Made in France by Sef Laval
TECHNICAL CHARACTERISTICS
Vinyl
Water-based polyurethane
Thickness (µ)
60
Includes transporter
Yes
Fabrics
Polyester, cotton, cotton-polyester and polyester-acrylic blends
Cutting blade for vinyl cutter
45º
Laser cutting
Yes
Discard
Hot/Tibium
TRANSFER PARAMETERS
Knife blade: 30-45º
Temperature: 165ºC
Time: 17 seconds
Pressure: 2.5 - 3.0 bar [medium pressure]
APPLICATION INSTRUCTIONS
Cut your design in mirror image with a cutter plotter
Weed out your excess vinyl
Preheat the press to 165ºC
Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
Position the vinyl over the garment and cover with protective paper
https://www.brildor.com/en/atomic-heat-transfer-vinyl-50-cm-roll27383Glossy Heat Transfer Vinyl - FlexCut Atomic from Sef Laval<p><a name="know-more"></a></p>
<h2>More information about the Glossy Heat Transfer Vinyl - FlexCut Atomic from Sef Laval</h2>
<p> </p>
<p><strong>INDEX</strong></p>
<p>> <a href="#know-more1">Description</a></p>
<p>> <a href="#know-more0">Technical characteristics</a></p>
<p>> <a href="#know-more2">Transfer parameters</a></p>
<p>> <a href="#know-more3">Application instructions</a></p>
<p>> <a href="#know-more4">Wash resistance</a></p>
<p>> <a href="#know-more6">Weight</a></p>
<p>> <a href="#know-more8">Colour card and data sheet</a></p>
<p> </p>
<p><a name="know-more1"></a></p>
<p><strong>DESCRIPTION</strong></p>
<p>FLEXCUT ATOMIC is a <strong>water-based PU</strong> (polyurethane) <strong>film</strong> for transferring your designs on fabrics without water-repellent impregnation.</p>
<ul>
<li>With a built-in liner</li>
<li>The raw materials are ecologically inert, do not contain PVC, plasticizers or heavy metals and are certified in accordance with <strong>Oeko-Tex Standard 100 Class II</strong></li>
<li>Made in France by Sef Laval</li>
</ul>
<p> </p>
<p><a name="know-more0"></a></p>
<p><strong>TECHNICAL CHARACTERISTICS</strong></p>
<table>
<tbody>
<tr>
<td><strong>Vinyl</strong></td>
<td>Water-based polyurethane</td>
</tr>
<tr>
<td><strong>Thickness (µ)</strong></td>
<td>60</td>
</tr>
<tr>
<td><strong>Includes transporter</strong></td>
<td>Yes</td>
</tr>
<tr>
<td><strong>Fabrics</strong></td>
<td>Polyester, cotton, cotton-polyester and polyester-acrylic blends</td>
</tr>
<tr>
<td><strong>Cutting blade for vinyl cutter</strong></td>
<td>45º</td>
</tr>
<tr>
<td><strong>Laser cutting</strong></td>
<td>Yes</td>
</tr>
<tr>
<td><strong>Discard</strong></td>
<td>Hot/Tibium</td>
</tr>
</tbody>
</table>
<p> </p>
<p><a name="know-more2"></a></p>
<p><strong>TRANSFER PARAMETERS<br></strong></p>
<ul>
<li>Knife blade: <span class="azul-negrita">30-45º</span></li>
<li>Temperature: <span class="azul-negrita">165ºC</span></li>
<li>Time: <span class="azul-negrita">17 seconds</span></li>
<li>Pressure: <span class="azul-negrita">2.5 - 3.0 bar</span> [medium pressure]</li>
</ul>
<p> </p>
<p><a name="know-more3"></a></p>
<p><strong>APPLICATION INSTRUCTIONS<br></strong></p>
<ul>
<li>Cut your design in <strong>mirror image</strong> with a cutter plotter</li>
<li>Weed out your excess vinyl</li>
<li>Preheat the press to <span class="azul-negrita">165ºC</span></li>
<li>Place the garment on the press and pre-press for <span class="azul-negrita">4-5 seconds</span> to remove wrinkles and moisture from the fabric</li>
<li>Position the vinyl over the garment and cover with protective paper</li>
<li>Press for <span class="azul-negrita">17 seconds</span>, medium pressure</li>
<li><strong>Warm peel</strong> the liner</li>
</ul>
<p> </p>
<p><a name="know-more4"></a></p>
<p><strong>WASH RESISTANCE</strong></p>
<ul>
<li>Washing resistance: <span class="azul-negrita">60ºC</span> max</li>
</ul>
<p> </p>
<p><a name="know-more6"></a></p>
<p><strong>Weight</strong></p>
<table>
<tbody>
<tr>
<td>Roll</td>
<td><span class="azul-negrita">25 x 1</span></td>
<td><span class="azul-negrita">50 x 2</span></td>
<td><span class="azul-negrita">50 x 10</span></td>
</tr>
<tr>
<td>Weight (kg)</td>
<td><span class="azul-negrita">0.108</span></td>
<td><span class="azul-negrita">0.24</span></td>
<td><span class="azul-negrita">1.2</span></td>
</tr>
</tbody>
</table>
<p> </p>
<p><a name="know-more8"></a></p>
<p><strong>COLOUR CARD AND DATA SHEET<br></strong></p>
<p><a title="LaserFlex Atomic colour card and data sheet" href="https://www.brildor.com/media/upload/descargas/Ficha_Tecnica_Vinilo_Textil_FlexCut_Atomic_Sef_Laval.pdf" target="_blank" rel="nofollow noopener">LaserFlex Atomic colour card and data sheet (pdf - 0.437 MB)</a></p>https://www.brildor.com/media/catalog/product/v/i/vinilo-textil-atomic-d19.jpg65.19instock065.19000https://www.brildor.com/media/catalog/product/v/i/vinilo-textil-atomic-d19.jpg2206627379/Vinyl/Vinyl/Cutting Heat Transfer Vinyl/Blanks/Blanks/Materials for Laser/Blanks/Materials for Laser/Vinyl2021-07-24T06:06:11+0000
