Self Adhesive Vinyl for Sublimation and Laser Printing - Washaffix

More information about the Washaffix self-adhesive vinyl for sublimation and laser printing

INDEX

> Description

> Things to keep in mind

> Sublimation settings

> Sublimation instructions before sticking it on

> Sublimation instructions after bonding

> Weights

> Storage recommendations

DESCRIPTION

WASHAFFIX is a vinyl for rigid surfaces such as ceramic, plastic, wood, glass, aluminium and more.

• This vinyl can be printed using 2 different methods: directly with a laser printer or using dye sublimation printing. Moreover, there are 2 options to sublimate it: before or after sticking it to the surface of the object you want to personalise, as long as it resists heat
• Printable using dry toner (both monochrome and colour), white toner, LED technology or flash fusing
• Permanent acrylic adhesive
• Suitable for plotter cutting. PVC-free, can also be laser cut
• Durable due to no water absorption and high adhesive tack
• Dishwasher safe up to 60ºC

THINGS TO KEEP IN MIND

• Avoid using the microwave on personalised glasses, cups or plates with Washaffix
• If you want to get higher opacity, we recommend using the matte white. This will prevent the colour of the object on which it is applied from blending with the colours of the design
• To show the colour of the object in combination with the design, use the transparent one
• When printing by dye sublimation let the ink dry for 48-72 hours
• If you use a Silhouette Cameo cutting plotter apply the following parameters: blade 2, force 20 and passes 1
• Transparent Washaffix needs less time, temperature and pressure than the matte white vinyl (see sublimation settings)
• Use a squeegee to adhere the vinyl and avoid the formation of air bubbles

SUBLIMATION SETTINGS

MATTE WHITE

• Temperature: 200ºC
• Time: 50 seconds
• Pressure: 6 bar [very high pressure]

CLEAR

• Temperature: 190ºC
• Time: 35 seconds
• Pressure: 2.0 - 3.0 bar [low pressure]

SUBLIMATION INSTRUCTIONS BEFORE STICKING IT ON

MATTE WHITE

• Print the design in mirror image on sublimation paper
• Preheat the press to 200ºC
• Place the vinyl on the press with the sublimation side facing up and the design printed on it
• Cover both with protective paper
• Press for 50 seconds, medium pressure
• Remove the protective paper and the printed vinyl
• If needed, cut the design with a vinyl cutter, scissors or a box cutter
• Peel off the liner and adhere it to the desired surface with the help of a spatula

CLEAR

• Print the design in mirror image on sublimation paper
• Preheat the press to 190ºC
• Remove the vinyl from the liner and stick it to protective paper or any other silicone paper. Use a spatula to avoid air bubbles or wrinkles. Do not throw away the liner because you will need it later
• Place the vinyl on the press with the sublimation side facing up and the design printed on it
• Cover both with protective paper
• Press for 35 seconds, low pressure
• Reattach the sublimated vinyl to the liner with the help of a spatula

• Wipe off any ink residue on the vinyl with a dry cloth
• Cut it preferably with a plotter
• Peel off the liner and adhere it to the desired surface

SUBLIMATION INSTRUCTIONS AFTER BONDING

MATTE WHITE

• Cut and stick the vinyl to the object you want to personalise
• If necessary, use heat-resistant tape to protect the parts of the item that may get damaged by the heat of the press
• Print the design in mirror image on sublimation paper
• Preheat the press to 200ºC
• Place the item on the press with the vinyl facing upwards
• Put the printed paper with the design on top of the vinyl
• Cover both with protective paper
• Press for 50 seconds, low pressure
• Using a protective glove, remove the newly printed item from the press

CLEAR

• Cut and stick the vinyl to the object you want to personalise
• If necessary, use heat-resistant tape to protect the parts of the item that may get damaged by the heat of the press
• Print the design in mirror image on sublimation paper
• Preheat the press to 190ºC
• Place the item on the press with the vinyl facing upwards
• Put the printed paper with the design on top of the vinyl
• Cover both with protective paper
• Press for 35 seconds, low pressure
• With the help of a protective glove, remove the finished sublimated item

• Carefully peel off the paper

WEIGHTS

STORAGE RECOMMENDATIONS

• Shelf life of 18 months if stored properly
• Store in a place at -40ºC to 60ºC and a relative humidity of 20% to 55%
