Thermo-adhesive. Fixable by heat using a heat press
Suitable for a vinyl cutter
Easy to apply: (1) cut the foil to the shape of the design and transfer it to the textile; (2) adhere the foil, flock or patch onto the applied adhesive
The 25 m roll has a Ø7.5 cm cardboard core
Made in Germany by Poli-Tape
THINGS TO KEEP IN MIND
Testing is recommended for water-repellent coated fabrics such as soft shell or similar
TECHNICAL DETAILS
Film
Poli-Melt Turbo 4900
Poli-Melt Nylon 701
Thickness (µ)
42
50
Recommended fabric
Cotton, polyester and blends
Nylon
Adhesive
Co-polyester hot melt
Polyamide
Liner
Self-adhesive PET film
Silicone paper
TRANSFER PARAMETERS
TURBO 4900
It can be applied at different temperatures:
Temperature - Time:
130ºC - 5 seconds
150ºC - 4 seconds
160ºC - 3 seconds
Pressure: 2.5 - 3 bar [medium pressure]
Pre-pressing of the garment: 4-5 seconds
Hot peel
NYLON 701
Temperature: 145 - 155ºC
Pressure: 2 - 3 bar [medium pressure]
Time: 15 - 18 seconds
Pre-pressing of the garment: 4-5 seconds
APPLICATION INSTRUCTIONS
Instructions and parameters for guidance only. We recommend carrying out tests to establish the parameters that best suit the fabric used.
TURBO 4900
Cut the film with the design in mirror mode or to the size of the patch to adhere
Peel off the heat-adhesive film, discarding the transparent part that does not cover the design. This way, only the clear layer with the shape of the design will remain on the liner
Pre-press the garment for 3-4 seconds to remove wrinkles and dampness
Place the film on the garment where you want to apply the adhesive and cover it with protective paper
Press at 130ºC (5 seconds), 150ºC (4 seconds) or 160ºC (3 seconds), medium pressure
Hot peel the protective paper and liner
Place the foil, flock or patch on the hot melt foil applied on the garment. The foil should be placed with the coloured side facing upwards, while the flock with the velvet side facing downwards
Press at 130ºC (5 seconds), 150ºC (4 seconds) or 160ºC (3 seconds), medium pressure
If you have used foil or flock, cold peel it with a smooth and continuous movement
NYLON 701
Preheat the press to 145-155ºC
Cut the film with the design in mirror mode or to the size of the patch to be adhered
Peel off the heat-adhesive film, discarding the transparent part that does not cover the design. This way, only the clear layer with the shape of the design will remain on the liner
Pre-press the garment for 3-4 seconds to remove wrinkles and dampness
Place the film on the garment where you want to apply the adhesive and cover it with protective paper
Press for 15-18 seconds, medium pressure
Hot peel the protective paper and liner
Place the foil, flock or patch on the hot melt foil applied on the garment. The foil should be placed with the coloured side facing upwards, while the flock with the velvet side facing downwards
Press at 145-155ºC for 15-18 seconds, medium pressure
If you have used foil or flock, cold peel it with a smooth and continuous movement
WASH RESISTANCE
Wash at 60ºC maximum (TURBO 4900) and 40ºC maximum (Nylon 701)
Please follow the washing instructions for the fabric or garment used
WEIGHTS
TURBO 4900
Reference no
049761
049757
049756
Roll (cm x m)
25 x 2.5
50 x 5
50 x 25
Outer diameter (cm)
-
-
11
Weight (kg)
0.136
0.528
2.985
NYLON 701
Reference no
049760
049759
049758
Roll (cm x m)
25 x 2.5
50 x 5
50 x 25
Outer diameter (cm)
-
-
10.4
Weight (kg)
0.086
0.336
1.98
DATA SHEETS
We have adapted the formats to the needs of our customers, which may not match those listed in the following safety data sheet provided by the manufacturer.
When used under normal conditions, this product does not generate or release any dangerous substances or hazardous chemicals. This is a non-hazardous product in accordance with the current GefStoffV and EU criteria. Therefore it is not necessary to prepare a Material Safety Data Sheet for this product. The Safety Data Sheet serves only to comply with the regulation to supply information in accordance with REACH Regulation (EC) No. 1907/2006 and is available on request. This is not a hazardous product with regards to transportation legislation; neither does it contain substances that are hazardous to water within the meaning of the federal water act. After use, dispose of the waste product in accordance with the local/national authorities.
