Sublimation Heat Transfer Vinyl - SubliFlock FiberPlus from Sef Laval

INDEX

Description

Things to keep in mind

Sublimation parameters

Transfer parameters

Application instructions

Wash resistance

Storage recommendations

Data sheet

DESCRIPTION

SUBLIFLOCK FIBERPLUS is a thermo-adhesive printable flock film (400 µ) for textile transfer.

• Can be cut with any type of plotter
• No transfer tape needed
• Made in France by Sef Laval

THINGS TO KEEP IN MIND

• For complex or detailed designs, it may be convenient to use application tape, see Related Products
• After printing the vinyl with sublimation ink, it should be left to dry. Transfer it to the garment once the ink is dry to the touch
• Print it using cut marks to cut it with the plotter

SUBLIMATION PARAMETERS

• Temperature: 190-210ºC
• Time: 30-40 seconds
• Pressure: low

TRANSFER PARAMETERS

• Knife blade: 30-45º
• Speed ≈40 cm/s
• Temperature: 160-170ºC
• Pressure: 2.5-3.0 bar [medium pressure]
• Time: 15-17 seconds

APPLICATION INSTRUCTIONS

STEP 1. DYE SUBLIMATION VINYL PRINTING

• Print the paper in mirror image
• Preheat the press to 190-210ºC
• Place the vinyl on the lower platen with the matte and velvety side facing upwards
• Put the printed side of the paper over the vinyl
• Press for 30-40 seconds, medium pressure
• Take the sublimated vinyl out of the press
• Let the ink dry

STEP 2. TRANSFERRING THE VINYL TO THE FABRIC

• When the ink is dry to the touch, cut the sublimated vinyl with the plotter
• Weed out your excess vinyl
• In case of using an application tape, stick it to the vinyl starting from the centre outwards, avoiding creasing the vinyl
• Preheat the press to 160-170ºC
• Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture
• Place the vinyl on the garment with the sublimated side facing upwards
• Cover with protective paper
• Press for 15-17 seconds, medium pressure
• Remove the transfer tape if you have used one
• Warm peel the liner

WASH RESISTANCE

• Washing resistance: 60ºC max

STORAGE RECOMMENDATIONS

• Store in a cool, dry place away from direct sunlight
• It is not recommended to keep the vinyl in storage for more than 36 months

DATA SHEET

Data sheet SubliFlock FiberPlus (.pdf - 0.36 MB)
